Empty dust bin

1.Lift up the dust bin cover
to separate from
the main body.
4. Shake the dust bin left/right to remove the waste inside.

Filter cleaning

1.Follow step 1 & 2 in <Empty dust bin> section to
2.Pull out the cleaning brush in the dust bin cover.
3. Open the dust bin fix clip as shown
in the picture then divide the blade from the dust bin.
Clean the inner part of the dust bin using cleaning brush.
1
separate the dust bin cover.
3. Divide the filtering device from dust bin as
shown in the picture then separate the filter.
2. Hold the dust bin
holder and lift up then
separate it from
the main body.
2
5.Close the
blade then
insert it to
the main body.
