User Manual
Model Name
eX300
Power
100 V ~ 240 V
Standby energy consumption
Main body energy consumption
Battery
Lithium lon Battery
Diameter
Height
Weight
Speed
300 mm/s (Max.)
Filter
Antibacterial filter
Sensor
IR, PSD, Encoder, Bumper
Charging Time
Usage Time
120 min.
Noise Level
Yujin Robot Customer Support : 1.855.926.1601
ㆍMonday-Friday 9 am to 6pm PST
Closed
ㆍSaturdays
Closed
ㆍSundays
MADE IN KOREA
©2014 Yujin Robot Inc.
16410 Manning Way, Cerritos, CA 90703
support@yujinrobotusa.com
T 562.926.1601 F 562.926.1629
www.yujinrobotusa.com
One-Year Limited Warranty.
Specifications and features are subjected to change without notice.
(YCR-M05-P )
*
Below 1 W
10 W
13.8 inches
3.5 inches
6.06 Ibs
110 min.
(based on normal floor)
58 dB[A]
iPMN.USA.300.V0
YCR-M05
User Guide
Robotic Vacuum Cleaner eX300
■Please be sure to read the Safety Precautions before use.
