shutdown diagnostics

The unit has the ability to report the cause of the last shutdown of the remote start system.
To enter diagnostic mode:
1.
2.
3.
4.
5.
The LED will now report the last system shutdown by flashing for one minute in the following grouped patterns:
The LED will stop flashing when the ignition is turned on.
40
Turn the ignition off.
Press and HOLD the Valet/Program switch.
Turn the ignition on and then off.
Release the Valet/Program switch.
Press and release the Valet/Program switch.
LED FLASHES SHUTDOWN MODE
One System timed out
Two Over-rev shutdown
Three Low or no RPM
Four Transmitter Shutdown (or optional push-button)
Five (-) Shutdown
Six (+) Shutdown
Seven (-) Neutral safety shutdown (H3/6 BLACK/WHITE)
Eight Wait-to-start timed out
