  • Page 1 R R e e s s p p o o n n d d e e r r 4 4 6 6 0 0 ➤ O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: L L I I M M I I T T E E D D L L I I F F E E T T I I M M E E C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y

    L L i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y Directed Electronics ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), exclud-...
  • Page 3 Authorized dealer's company name and address ➤ Type of alarm installed ➤ Year, make, model and color of the automobile ➤ Automobile license number ➤ Vehicle identification number ➤ All security options installed on automobile ➤ ➤ Installation receipts © 2008 directed electronics...

  • Page 4: Table Of Contents

    Interpreting zone diagnostics........30 © 2008 directed electronics...
  • Page 5 Q Q u u i i c c k k r r e e f f e e r r e e n n c c e e g g u u i i d d e e ....................4 4 5 5 © 2008 directed electronics...
  • Page 6 2 2 - - w w a a y y L L C C D D r r e e m m o o t t e e c c o o n n t t r r o o l l Auxiliary Channel Button Arm Button LCD Screen (see LCD Screen) Disarm Button Panic Button Battery Compartment Program Button © 2008 directed electronics...

  • Page 7: L L C C D D S S C C R R E E E E N

    12. Vibrate mode 4. Aux Output 2 or 3 13. Ignition 5. Garage door (519H2 option) 14. Vehicle number 6. Warn Away 15. Door ® 7. Alarm 16. Arm 8. Trunk or Hood 17. Disarm Sensor © 2008 directed electronics...

  • Page 8: S S T T A A N N D D A A R R D D R R E E M M O O T T E E C C O O N N F F I I G G U U R R A A T T I I O O N

    A A u u x x i i l l i i a a r r y y O O u u t t p p u u t t ( ( 3 3 ) ) . (located on back of the remote) selects the vehicle to control and also provides user selection of LCD remote response . © 2008 directed electronics...

  • Page 9: W W H H A A T T I I S S I I N N C C L L U U D D E E D

    All dealers are provided with preprinted dealer certifi- cates to verify that they are authorized. This owner’s guide should help you to get the most out of your system. Please take the time to read it prior to using the system. © 2008 directed electronics...

  • Page 10: System Maintenance

    Your warranty registration must be returned and the bar code serial number must not be removed. If the warranty registration is not returned, you do not have a warranty. It is also necessary to © 2008 directed electronics...

  • Page 11: Fcc/Id Notice

    (2) This device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device. © 2008 directed electronics...

  • Page 12: R R E E P P L L A A C C E E M M E E N N T T R R E E M M O O T T E E C C O O N N T T R R O O L L S

    Programming LCD Remote section). ➜ Standard configurations (1-way and 2-way remote controls) Button The arming function is controlled by pressing this button for one second. Button The disarming function is controlled by pressing this button for one second. © 2008 directed electronics...
  • Page 13 (on rear of 2-way LCD remote only) Program Button Use this button to select the vehicle to control from the remote. Also use this button to configure response characteristics from the LCD remote (see Programming 2-Way Remote). © 2008 directed electronics...

  • Page 14: Standard Lcd Icon Configurations (2-Way Only)

    The above Warn Away displays when a security feature has been ® tripped, but not to full alarm. Icons The above icons will display when a security feature has been tripped to a full alarm condition. © 2008 directed electronics...
  • Page 15 4 vehicles) being controlled by the remote. If a Warn Away ® or alarm trigger should occur at one of the other vehicles, that vehicle’s number will be displayed and the LCD will display that vehicle’s status. To change back to the original vehicle selected, © 2008 directed electronics...
  • Page 16 The arm icon will flash when the system is locking the doors and display continuously until the system is armed. Icon The disarm icon will flash when the system is unlocking the doors and display continuously until the system is disarmed. © 2008 directed electronics...

  • Page 17: R R E E M M O O T T E E O O P P E E R R A A T T I I O O N

    LCD Icons will display the current system status. Command Page When a command (arm/disarm, or auxiliary channel) from the remote control is sent and received, the system will send a command page back to confirm receipt. © 2008 directed electronics...

  • Page 18: Out Of Range Notification

    If a command is issued from the remote, but the remote is set to the incorrect vehicle or is beyond the range of the vehicle to receive the command, the remote responds with 3 set of 2 quick beeps and the icon will flash 3-times. © 2008 directed electronics...

  • Page 19: P P R R O O G G R R A A M M M M I I N N G G L L C C D D R R E E M M O O T T E

    Beep & Vibrate 1-beep and 1-vibrate Vibrate and siren No Beep and No Vibrate 1 long beep icons Off * * N N o o t t e e : : This is icon display during programming. © 2008 directed electronics...

  • Page 20: Illumination On/Off

    N N o o t t e e : : If programmed Off, n n o o a a l l a a r r m m s s will be notified to the remote. Command information (armed/disarmed) will be noti- fied to the remote. ➜ To exit programming mode The LCD remote control will exit programming mode after 5- seconds of inactivity and will emit 2 long beep. © 2008 directed electronics...

  • Page 21: U U S S I I N N G G Y Y O O U U R R S S Y Y S S T T E E M

    If the LCD remote beeps twice after arming, the system has detected an active sensor that should be checked. For example, a door open icon will be displayed flashing 5-times on the LCD screen. © 2008 directed electronics...

  • Page 22: Passive Arming

    1 to 180 seconds. ➤ If a door is opened, the system will immediately start © 2008 directed electronics...

  • Page 23: Multi-Level Security Arming

    ➤ Press once: The siren chirps once. The system is armed. ➤ Press a second time within five seconds: The siren chirps twice followed by a long chirp. Zone 2 is now bypassed. © 2008 directed electronics...

  • Page 24: Disarming

    If the power locks are connected to the system, the doors will unlock. If the siren chirps either four or five times when disarming, refer to the Diagnostics section of this guide. This is called Tamper Alert. © 2008 directed electronics...
  • Page 25 4 quick beeps and the LCD screen will indicate which switch (5 flashes) tripped the alarm. 3. If the system was triggered so many times that NPC is active the remote will emit the above notifications with 5 beeps instead of 4. © 2008 directed electronics...

  • Page 26: Disarming Without A Transmitter

    Valet button for the disarm func- tion. Be sure to check with the installer for the desired programming. The LCD remote will indicate disarm notification with 4 quick beeps and 5 flashes of the and triggered zone icons. © 2008 directed electronics...

  • Page 27: Dome Light Control (Optional)

    Silent Mode. This ensures that no chirps will be emitted by the siren in an area you want chirp-free. The system is still fully capable of triggering. Only the Warn Away response is bypassed. ® © 2008 directed electronics...

  • Page 28: Panic Mode

    Panic Mode. The siren will sound and the parking lights will flash for the programmed siren duration. To stop Panic Mode at any time, press , or on the remote transmitter again. © 2008 directed electronics...

  • Page 29: Valet Mode

    Quickly press the following buttons in the sequence indicated. 2. Press 3. Press 4. Press again. The in-vehicle status LED will light solidly if you are entering Valet Mode, and it will go out if you are exiting Valet Mode. ® ® © 2008 directed electronics...

  • Page 30: Nuisance Prevention Circuitry

    NPC has been engaged. If you wish to clear the ® memory, turn the ignition key on. ® is On/Off programmable. See your dealer and the ® Programming section of this guide for more information. © 2008 directed electronics...

  • Page 31: A A U U X X I I L L I I A A R R Y Y O O U U T T P P U U T T S S ( ( O O P P T T I I O O N N S

    The remote will respond with a page notification consisting of one long beep and for 4 seconds displays the channel number on the LCD screen. This occurs at the remote after the system has received the command to activate any of the Auxiliary outputs. © 2008 directed electronics...

  • Page 32: D D I I A A G G N N O O S S T T I I C C S

    Bypass Notification chirps. Once the light shuts off, however, the doors are monitored normally. © 2008 directed electronics...

  • Page 33: Disarming Diagnostics

    Action Number of Chirps Description System armed 1 (3-second delay), 1 System armed with Bypass Notification Disarm System disarmed Disarm System disarmed with Tamper Alert ® Disarm System disarmed NPC active © 2008 directed electronics...

  • Page 34: Table Of Zones

    Instant trigger - often used for trunk pinswitches Shock sensor input - a light impact activates warn away and a heavier impact activates full alarm. Door switch trigger Optional sensor inputs for warn away and full alarm notification. Ignition trigger © 2008 directed electronics...

  • Page 35: Interpreting Zone Diagnostics

    To re-sync the remote control press © 2008 directed electronics...
  • Page 36 It is almost like having four separate alarms in your vehicle, one for each user. note: Owner Recognition cannot be programmed with- ® out a Directed Bitwriter and the necessary software. Check with your dealer for more information. © 2008 directed electronics...

  • Page 37: R R A A P P I I D D R R E E S S U U M M E E L L O O G G I I C

    Valet Mode, the LED will shut ® off. If the system remains in Valet Mode, the LED will ® come back on the next time the ignition is turned on and then back off. © 2008 directed electronics...

  • Page 38: P P R R O O G G R R A A M M M M I I N N G

    (only when arming with the remote). Passive locking allows the vehicle's doors to lock when the security system passively arms (after the 30 second countdown). This feature only works if passive arming has been programmed. © 2008 directed electronics...
  • Page 39 AED arming cycle. Thirty seconds later, the starter of the vehicle will be disabled. To start the car, it will be necessary to disarm the system with the remote. It is also possible to disarm the AED © 2008 directed electronics...
  • Page 40 Forced Passive Arming Off is left open the system will be armed after 30-seconds. ➤ : Prevents the Panic button on the remotes Panic with Ignition Off from activating panic with ignition On (not allowed in some states). © 2008 directed electronics...
  • Page 41 © 2008 directed electronics...

  • Page 42: I I N N S S T T A A L L L L A A T T I I O O N N O O P P T T I I O O N N S

    (after several progressive warnings) as safely as possible. Should a carjacking occur, the VRS allows you to concern yourself with your personal safety without worrying about your property. © 2008 directed electronics...

  • Page 43: Arming The Vrs

    To protect against parking lot carjacking, arm the VRS before leaving the ve- hicle. The system will now trigger automatically the next time you or anyone drives the vehicle. This helps to protect the vehicle © 2008 directed electronics...

  • Page 44: Triggered Sequence, Vrs

    The starter kill will remain active until the system is disarmed. If the door is opened or the ignition is turned off and on in an attempt to restart the car, the siren and light flashing will begin again. © 2008 directed electronics...

  • Page 45: Disarming The Vrs

    ® the ignition must be turned off, then on to disarm. If you are driving the vehicle at the time, pull to a safe place away from traffic and follow the triggered sequence dis- arm procedure. © 2008 directed electronics...
  • Page 46 ® Headlight and Parking Light Automation: will automatically turn on your parking and headlights when it gets dark. In addition, the 545T will turn your headlights on whenever the windshield wipers are used. A transmitter function © 2008 directed electronics...
  • Page 47 U U l l t t r r a a s s o o n n i i c c S S e e n n s s o o r r : : Providing a field of protection inside your car using the 509U Ultrasonic sensor to protect your belongings. © 2008 directed electronics...
  • Page 48 : This is a sensor mounted in the vehicle that is Shock Sensor designed to pick up impacts to the vehicle or glass. : Noise generating device usually installed in the engine Siren compartment of the vehicle. It is responsible for generating the © 2008 directed electronics...
  • Page 49 : A zone is a separate input that the alarm can recognize as Zone unique. Each input to the system is connected to a particular zone. Two or more inputs often share the same zone. © 2008 directed electronics...

  • Page 50: Quick Reference Guide

    To activate Silent Mode™ Press briefly before arming or disarming, and the confirmation chirp(s) will be ➤ eliminated for that one operation only. Location of Valet ® Button_______________________________ Number of Valet ® Button pulses for disarming_____________ © 2008 directed electronics...
  • Page 51 100 patents in the field of advanced electronic technology, Directed is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 274-0200 for more information about our products and services.
