446 Series
Installation Guide
NOTE:
This product is intended for installation by a professional installer only!
Any attempt to install this product by any person other than a trained professional
may result in severe damage to a vehicle's electrical system and components.
© 2002 Directed Electronics, Inc. Vista, CA
N446V 10-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 446 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Electronics 446 Series

Summary of Contents for Directed Electronics 446 Series

  • Page 1 This product is intended for installation by a professional installer only! Any attempt to install this product by any person other than a trained professional may result in severe damage to a vehicle’s electrical system and components. © 2002 Directed Electronics, Inc. Vista, CA N446V 10-02...
  • Page 2 Soft Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of Directed Electronics, Inc. w w w w w w . . d d i i r r e e c c t t e e c c h h s s . . c c o o m m D D i i r r e e c c t t F F a a x x 8 8 0 0 0 0 - - 9 9 9 9 9 9 - - 1 1 3 3 2 2 9 9 T T e e c c h h n n i i c c a a l l S S u u p p p p o o r r t t 8 8 0 0 0 0 - - 7 7 5 5 3 3 - - 0 0 8 8 0 0 0 0 These resources are for authorized Directed Dealer use only.

  • Page 3: Table Of Contents

    R R a a p p i i d d R R e e s s u u m m e e L L o o g g i i c c ..............................................3 3 7 7 © 2002 Directed Electronics, Inc.

  • Page 4: Primary Harness Wiring Diagram

    NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window automation, pager or voice module a 1Amp diode must be installed to ensure proper operation. Insert the diode as shown in the following diagram. IMPORTANT! Never interrupt any wire other than the starter wire. © 2002 Directed Electronics, Inc.
  • Page 5 SPDT relay must be used on the H1/2 light flash output wire. IMPORTANT! DO NOT connect this wire to a negative vehicle light flash wire before changing the programming jumper to the negative polarity position or damage to vehicle light circuit may occur. © 2002 Directed Electronics, Inc.
  • Page 6 See DirectFax document 1076 for wiring instructions. This wire will report Zone 3. NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6, or the 998T Bitwriter can be used to turn Bypass Notification off. © 2002 Directed Electronics, Inc.
  • Page 7 DOES NOT have any vehicle component grounds attached to it. A screw should only be used when in conjunction with a two-sided lock washer. Under dash brackets and door sheet metal are not acceptable ground points. It is recommended that all security components be grounded at the same location. © 2002 Directed Electronics, Inc.
  • Page 8 The relay can drive circuits up to 20 amperes. The polarity of this output is deter- mined by the connection of the input wire H2/A in the Relay Harness. NOTE: If the input wire H2/A is not connected, there will be no output from the relay when it is activated. © 2002 Directed Electronics, Inc.

  • Page 9: Relay Harness Wiring Diagram

    H2/C - H2/H power door locks The system has door lock relays on-board, and can directly interface with most electric power door lock systems drawing 30 amps or less. It can also drive aftermarket actuators directly. © 2002 Directed Electronics, Inc.

  • Page 10: Identifying The Door Lock System

    T T y y p p e e H H - Negative (-) multiplex. A Resistor Interface Module (GM P/N 12496739) may be used for this type of door locking system. This system is found in 1999 and newer Grand Am and Alero models, as well as 2000 and newer Impala and Monte Carlo models. © 2002 Directed Electronics, Inc.

  • Page 11: Type A: Positive-Triggered, Relay-Driven System

    Door Lock Harness (H2) Wire Connection Guide section. Depending on the type of door lock system, there may be additional H2 harness wires that are not used for wiring the door locks. © 2002 Directed Electronics, Inc.

  • Page 12: Type B: Negative-Triggered, Relay-Driven System

    Door Lock Harness (H2) Wire Connection Guide section. Depending on the type of door lock system, there may be additional H2 harness wires that are not used for wiring the door locks. © 2002 Directed Electronics, Inc.

  • Page 13: Type C: Reversing Polarity System

    NOTE: Most direct-wired power lock systems require 20-30 amps of current to operate. Connecting the violet/black wire to a poor source of voltage will keep the door locks from operating properly. © 2002 Directed Electronics, Inc.
  • Page 14 Door Lock Harness (H2) Wire Connection Guide section. Depending on the type of door lock system, there may be additional H2 harness wires that are not used for wiring the door locks. © 2002 Directed Electronics, Inc.

  • Page 15: Type D: Adding One Or More After-Market Actuators

    Vehicles without factory power door locks require the installation of one actuator per door. This requires mounting the door lock actuator inside the door. Other vehicles may only require one actuator installed in the driver's door if all door locks are operated when the driver's lock is used. © 2002 Directed Electronics, Inc.

  • Page 16: Type E: Electrically-Activated Vacuum

    LOCK #87 NORMALLY OPEN (INPUT) GROUND H2/F BROWN/BLACK UNLOCK #87A NORMALLY CLOSED TO ELECTRIC UNLOCK H2/G BLUE/BLACK UNLOCK #30 COMMON (OUTPUT) VACUUM PUMP #87a H2/H TO 12 VOLTS VIOLET UNLOCK #87 NORMALLY OPEN (INPUT) DIA-94 © 2002 Directed Electronics, Inc.

  • Page 17: Type F: One-Wire System

    It is found in the late-model Nissan Sentra, some Nissan 240SX, and Nissan 300ZX 1992-up. It is also found in some Mazda MPV's. IMPORTANT! Remember that the violet jumper between the #87 lock terminal and the #87 unlock terminal must be cut. © 2002 Directed Electronics, Inc.

  • Page 18: Type G: Positive (+) Multiplex

    Door Lock Harness (H2) Wire Connection Guide section. Depending on the type of door lock system, there may be additional H2 harness wires that are not used for wiring the door locks. © 2002 Directed Electronics, Inc.

  • Page 19: Type H: Negative (-) Multiplex

    Two-Resistor Type If two resistors are used in the factory door lock switch/key cylinder, the door lock switch/key cylinder will read resistance to ground in both directions. Determining the Proper Resistor Values © 2002 Directed Electronics, Inc.
  • Page 20 Harness (H2) Wire Connection Guide section. Depending on the type of door lock system, there may be additional H2 harness wires that are not used for wiring the door locks. Type H Door Lock System Wiring Diagram: © 2002 Directed Electronics, Inc.

  • Page 21: Super Bright Led, 2-Pin White Plug

    Check for rear clearance before drilling a 9/32-inch hole and mounting the button.The GRAY wire in the two-pin plug may also be used as a (+) ghost switch input and can be connected to any (+) switch in the vehicle. (See Feature Descriptions section of this guide.) © 2002 Directed Electronics, Inc.

  • Page 22: Programmer Interface, 3-Pin Black Plug

    4. Route the receiver/antenna cable to the control module and plug it into the four-pin antenna connector. IMPORTANT! To achieve the best possible range, DO NOT leave the antenna cable bundled under the dash. Always extend the cable full length during installation, regardless of the antenna mounting location. © 2002 Directed Electronics, Inc.

  • Page 23: Shock Sensor Harness, 4-Pin White Plug

    Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8 seconds will trigger full alarm sequence and report Zone 2. RED (+) 12V Constant and BLACK (-) Ground Do not use these for anything besides the plug-in shock sensor. © 2002 Directed Electronics, Inc.

  • Page 24: Light Flash Jumper

    IMPORTANT! DO NOT connect the H1/2 light flash wire to a negative vehicle light flash wire before changing the programming jumper to the negative polarity position or damage to vehicle light circuit may occur. © 2002 Directed Electronics, Inc.

  • Page 25: Bypassing Sensor Inputs

    H1/6 BLUE wire, all trigger inputs except the door trigger input will remain bypassed until five seconds after ground is removed from the BLUE wire. This can be done using the status output of a Directed Electronics remote engine starting unit as shown in the following diagram: BLUE WIRE H1/6...
  • Page 26 6. R R e e l l e e a a s s e e t t h h e e V V a a l l e e t t / / P P r r o o g g r r a a m m S S w w i i t t c c h h . . Once a feature is programmed: Other features can be programmed within the same menu. Another menu can be selected. The learn routine can be exited if programming is complete. © 2002 Directed Electronics, Inc.
  • Page 27 Menu #2. To exit the learn routine do one of the following: Close the open door. Turn the ignition on. No activity for longer than 15 seconds. Press the Valet/Program switch too many times. © 2002 Directed Electronics, Inc.

  • Page 28: Menu #1 - Basic Features

    Ignition-controlled domelight OFF Single unlock pulse Double unlock pulse Channel 3: Validity Channel 3: latched/latched, reset with ignition/30-second timed/ second unlock output* *Second unlock is only available if Feature 2-8 is programmed to single pulse. © 2002 Directed Electronics, Inc.

  • Page 29: Menu #1 - Basic Features

    Audi, require longer lock and unlock pulses to operate the vacuum pump. Programming the system to provide 3.5 second pulses, will accommodate the door lock interface in these vehicles. The default setting is 0.8 second door lock pulses. © 2002 Directed Electronics, Inc.

  • Page 30: Menu #2 - Advanced Features

    During that hour, if the system detects a trigger on that zone again, the system resets the one hour timer. If one hour passes and the zone has not triggered © 2002 Directed Electronics, Inc.
  • Page 31 TIMED/SECOND UNLOCK OUTPUT: Channel 3 can be programmed for these output configu- rations. The unit is set to the default validity output. To change the configuration, use the two-chirp setting to toggle to the different configurations. © 2002 Directed Electronics, Inc.
  • Page 32 Remote Start or other accessories WHITE/BLUE Arm only Disarm only Panic only Auto-learn Standard Configuration* Auto-learn Single Button Arm/Disarm Configuration* Delete all transmitters *NOTE: For Auto Learn Configurations, see Transmitter Configurations section of this guide. © 2002 Directed Electronics, Inc.
  • Page 33 One long chirp indicates that Learn Routine has been exited. Learn Routine will be exited if any of the following occurs: Ignition is turned off. Door is closed. Valet/Program button is pressed too many times. More than 15 seconds elapse between steps. © 2002 Directed Electronics, Inc.

  • Page 34: Standard Configuration

    Single Button Arm/Disarm Configuration When programmed for single button arm/disarm configuration, the transmitter buttons are assigned to the following functions: operates Arm/Disarm/Panic operates Channel 2 and Silent Mode operate Channel 3 © 2002 Directed Electronics, Inc.

  • Page 35: Arm/Disarm Diagnostics

    0.8 seconds will trigger a Warning Zone response, while inputs longer than 0.8 seconds will instantly trigger the full alarm sequence. Two-stage (similar to doors) Ignition input. H1/9 YELLOW. NOTE: The Warn Away® response does not report on the LED. © 2002 Directed Electronics, Inc.

  • Page 36: Long Term Event History

    VRS is an optional feature designed to disable a vehicle during a carjacking event. It must be programmed in the features menu and the Failsafe Starter Kill must be installed for it to work properly. For operational instructions when testing VRS refer to the Owner's Guide. © 2002 Directed Electronics, Inc.

  • Page 37: Rapid Resume Logic

    Closing the door triggers the system, but opening the door does not. Have you correctly identified the type of door switch system? This happens often when the wrong door input has been used. © 2002 Directed Electronics, Inc.
  • Page 38 Is it plugged into the correct socket? Check the System Features Learn Routine for the programmed Valet pulse count. Status LED doesn’t work. Make sure that it is plugged in. (See Plug-In Harnesses section of this guide.) Is the LED plugged into the correct socket? © 2002 Directed Electronics, Inc.

  • Page 39: Wiring Quick Reference Guide

    Wiring Quick Reference Guide © 2002 Directed Electronics, Inc.
