Summary of Contents for Directed Electronics Rattler 431R Series
- Page 1 431R Series Owner's Guide...
-
Page 3: Limited Lifetime Consumer Warranty
Contact your authorized dealer to obtain the ser- vice charge for your unit. These systems are a deterrent against possible theft. Directed Electronics, Inc. is not offering a guarantee or insuring against the theft of the automobile or its contents and disclaims any liability for the theft of the vehicle and/or its contents. - Page 4 This product warranty is automatically void if its date code or serial number is defaced, missing, or altered. This warranty will not be valid unless you have com- pleted the warranty card and mailed it to Directed Electronics, Inc. within 10 days after purchase to the address listed on the warranty registration card.
-
Page 5: Table Of Contents
..........17 Quick Reference Guide (Removable) 2000 Directed Electronics, Inc. ©... -
Page 6: Standard Configuration
Standard Configuration 2000 Directed Electronics, Inc. ©... -
Page 7: What Is Included
DEI’s website at www.directed.com. System Maintenance Your vehicle security system has no specific maintenance require- ments. The remote transmitter is powered by a miniature 12V battery, type GP23A, which has an approximate lifetime of one year 2000 Directed Electronics, Inc. ©... -
Page 8: Your Warranty
(2) This device must accept any inter- ference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device. 2000 Directed Electronics, Inc. ©... -
Page 9: Transmitter Functions
This auxiliary output controls_____________________________. NOTE: If using an optional four-button remote, the Standard Configuration may be assigned to buttons III and IV of the transmitter. 2000 Directed Electronics, Inc. © . (Silent Mode for less than one second. -
Page 10: Using Your System
NOTE: If any protected entry point, such as a door or switch-protected trunk or hood, is open, Passive Arming will not engage. Additionally, each time a sensor is triggered during the Passive Arming countdown, the countdown starts over. for one second. 2000 Directed Electronics, Inc. ©... -
Page 11: Disarming
The status LED will also stop flash- ing. The siren chirping either four or five times when disarming indicates Tamper Alert, which is described in the Diagnostics section of this guide. 2000 Directed Electronics, Inc. © ® response, causing the siren... -
Page 12: Disarming Without A Transmitter
1.5 seconds to trigger Panic Mode on your security system and attract attention. The siren will sound and the parking lights will flash for 30 seconds. To stop the Panic Mode at any time, press again. DRW-35 2000 Directed Electronics, Inc. ©... -
Page 13: Silent Mode
3. Press and release the Valet switch within 10 seconds. The status LED will light solidly if you are entering Valet Mode and will turn off if you are exiting Valet Mode. 2000 Directed Electronics, Inc. © before either arming or disarming. DRW-35... -
Page 14: Remote Valet
If the bypassed sensor is triggered again while it is already being bypassed, the 60-minute bypass period will start over. This ensures that a sensor that is continually being triggered will remain bypassed. ™ (NPC ™ ) to 2000 Directed Electronics, Inc. ©... -
Page 15: Diagnostics
Bypass Notification. A Bypass Notification chirp means that the system ignores the input that was active when the system was armed, until that input ceases. Three seconds after that input 2000 Directed Electronics, Inc. © ™ . If your secu- ™... -
Page 16: Disarming Diagnostics
A zone is represented by the number of LED flashes used by the system to identify a particular type of input. Standard input assign- ments are listed in the following table, along with spaces to write in any optional sensors or switches that you have had installed. 2000 Directed Electronics, Inc. ©... -
Page 17: Code-Hopping
To resynchronize the transmitter, simply press times within range of the vehicle. The system will automatically resynchronize and the transmitter will respond normally. 2000 Directed Electronics, Inc. © DEALER-INSTALLED OPTIONS ®... -
Page 18: High Frequency
Active door locking (only when arming with the transmitter) or passive door locking (selectable only when Passive Arming has been programmed). Arming and disarming confirmation siren chirps can be pro- grammed on or off. 2000 Directed Electronics, Inc. ©... -
Page 19: Security & Convenience Expansions
Backup Battery: The 520T Backup Battery ensures that the system stays armed, triggers the alarm and keeps the optional starter kill active if main battery power is disconnected. 2000 Directed Electronics, Inc. © ™... - Page 20 Start System can start your vehicle, monitor engine functions and activate your climate control system with a push of a button! Over- rev protection, open-hood lockout, brake pedal shutoff and automatic timer shutoff are included. (This option is available only for fuel-injected, automatic-transmission vehicles.) 2000 Directed Electronics, Inc. ©...
-
Page 21: Glossary Of Terms
Siren: A noise generating device, usually installed in the engine compartment of the vehicle. The siren generates the chirps and tones heard when the system is triggered. Transmitter: A hand-held, remote control that operates the vari- ous functions of the security system. 2000 Directed Electronics, Inc. ©... - Page 22 Zone: A zone is a separate input that the alarm recognizes as unique. Each input to the system is connected to a particular zone. Two or more inputs may share the same zone. 2000 Directed Electronics, Inc. ©...
- Page 23 Notes 2000 Directed Electronics, Inc. ©...
- Page 24 Notes 2000 Directed Electronics, Inc. ©...
-
Page 25: Quick Reference Guide (Removable)
First, open any vehicle door. Then press again. The status LED will light solidly if you have entered Valet Mode and will turn off if you have exited Valet Mode. 2000 Directed Electronics, Inc. © on the transmitter again. . Press... - Page 28 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 274-0200 for more information about our products and services.
