Page 1 DCS 6000 User Manual Digital Conference System DCS 6000 Conference Units Danish Interpretation Systems...
Page 2 Danish Interpretation Systems User Manual Copyright © 2009 DIS DCS6000 CONFERENCE UNITS REV H 01-09-2009 No part of this publication may be reproduced or utilised in any form or by any means without permission in writing from the publisher.
Page 3: Table Of Contents
Chip Card functionality ........29 Repacking ............4 The use of Chip Cards........29 Warranty ............4 User Controls & Indications ......29 Description of the DCS 6000 system ....5 DCS LAN Connectors ........30 Features.............. 5 System Setup............31 Central equipment & Interpreter equipment ... 5 General guidelines ...........31...
Page 4: Important
Warranty Installation precautions The individual units in the DCS 6000 system are Allow adequate air circulation to prevent internal minimum covered by 24 months warranty against heat built-up.
Page 5: Description Of The Dcs 6000 System
• “State of the Art” fully digital integrated System components interpretation, discussion and voting system The DCS 6000 system consists of various units in offering interpretation, language distribution, addition to the Conference Units. and conference microphone and voting facilities with attendance check with Chip Card ™.
Page 6: Operating Instructions
DCS 6000 Conference Units • Fixed or detachable microphone General description • ON/OFF button The DCS 6000 Conference Units are fully digital • Built-in loudspeaker microcomputer controlled conference units. All • units include a DSP processor (Digital Signal Language selector Processing).
Page 7 Danish Interpretation Systems User Manual CM/DM 6070P Portable Conference Unit Facilities: Fixed gooseneck, loudspeaker, two built-in channel selectors and two headphone connectors. Note: If the two channel selectors are in use (headphones inserted), the loudspeaker is disabled. CM/DM 6090P Portable Conference Unit Facilities: XLR microphone connector, loudspeaker, two built-in channel selectors and two headphone...
Page 8 Danish Interpretation Systems User Manual CM/DM 6060F Flush Mounted Conference Unit Facilities: Fixed gooseneck, loudspeaker, one built-in channel selector and one headphone connector. CM/DM 6510F Flush Mounted Conference Unit Facilities: Fixed gooseneck, loudspeaker, 3 voting buttons and Chip-card reader. Manual 01 18 04467...
Page 9 Danish Interpretation Systems User Manual CM/DM 6560F Flush Mounted Conference Unit Facilities: Fixed gooseneck, loudspeaker, 3 voting buttons, Chip-card reader, one built-in channel selector and one headphone connector. MU 6040 C/D Microphone Unit Available in Delegate (D) and Chairman (C) version The MU 6040 Microphone Unit is designed for hidden installation, e.g.
Page 10 Danish Interpretation Systems User Manual MU 6042D Dual Microphone Unit The MU 6042D Microphone Unit is designed for hidden installation, e.g. in an armrest, under a table or in a floor box for use with FD/FC series of front plates with Loudspeaker, Microphone and Buttons. Note: The MU 6042D does not support using HD 4042 Hand Microphone.
Page 11 The AM 6040 Ambient Microphone Unit is designed for installation above a recessed ceiling for connection to an external microphone like DIS model HM 4042 or GM 652x series of gooseneck microphones. The AM 6040 is delivered in a shielded metal mounting box like the MU 6040.
Page 12 Danish Interpretation Systems User Manual DC 6990P Conference Unit Facilities: 3.5’’ LCD colour touch screen, lockable XLR microphone connector, chip card reader, loudspeaker, two built-in channel selectors and two headphone connectors. The headphone connectors are designed for use headphones with stereo plug like the DH 6021. Configurable as Chairman Unit (CM), Delegate Unit (DM) and Dual Delegate Unit Quick Start Guide...
Page 13 Danish Interpretation Systems User Manual If a conference requiring chip card is running, the user is prompted to insert chip card before being granted access. Login using chip card If a conference requiring login code is running, the user is prompted to enter the code on the touch screen before being granted access.
Page 14 Danish Interpretation Systems User Manual The CM includes the microphone handling buttons: • All Del Off/All Req Off (active when the indicator is on the speaker and the request list, respectively) • Exclusive • Next On/Mic On/Mic Off (active when the indicator is on the first request on the request list, on the remaining requests on the request CM Main screen...
Page 15 Danish Interpretation Systems User Manual Menu screen When the user presses the Menu button, the menu screen with a menu overview appears. The overview gives access to extended functionality depending on whether it is running stand-alone or with the SW 6000: CM (stand-alone): Voting, Results, Audio, Logout CM (SW 6000): Conference, Voting, Agenda, Results, Audio, Logout...
Page 16 Danish Interpretation Systems User Manual Voting menu The Voting menu displays the available voting parameters. In stand-alone four parameters are available while with the SW 6000 all the parameters defined in the CAA will be available. The CM can scroll in the list using the scroll buttons and start a selected voting session or attendance check.
Page 17 Danish Interpretation Systems User Manual Results menu The Results menu displays the latest voting or attendance check result. CM Results menu DM Results menu Dual DM Results menu Audio menu The Audio menu contains volume and channel settings. Audio menu Manual 01 18 04467...
Page 18 Danish Interpretation Systems User Manual Logout menu The Logout menu allows the user to logout and return to the Start-up screen. Logout menu Voting The Voting screen is automatically displayed on all units when a voting session or attendance check is started.
Page 19 Danish Interpretation Systems User Manual Results The Results screen is displayed on all units when a voting session or attendance check is stopped. It displays the latest voting or attendance check result. CM Results screen DM Results screen Dual DM Results screen Setup menu The Setup menu can be accessed by holding down the scroll down button and then pressing the left...
Page 20 Danish Interpretation Systems User Manual Unit Type The Unit Type menu gives access to changing the unit type by selecting the desired unit type and exiting the menu. The CU has to be restarted in order for the changes to become effective. Unit type screen Left Btn.
Page 21: Microphone Functionality
Lights up with a green colour when the button is a DCS 6000 Conference Unit to address an pressed with the exception of the DC 6990P that audience. The sound from a conference microphone lights up with a red colour in the first release is called the ‘Floor’...
Page 22 Danish Interpretation Systems User Manual Mini-DIN microphone connector (only “F” models) A Mini-DIN microphone connector is located at the back for connection of FD/FC front plates with GM 65xx F series of gooseneck microphones. The HM 4042 Hand Microphone can also be connected. This connecter is intended for use, where the connection to the microphone is remotely from the front plate, which is only on customised units.
Page 23: Operation Modes
Danish Interpretation Systems User Manual The “System Operation Mode” also called ‘CU Operation modes mode’ determines the behaviour of the microphone system. The mode is set on the CU 60xx.. System modes The following modes are available when the CU The 6000 series microphones work in different 60xx runs standalone (PC with SW 6000 has never modes - according to the settings of the system.
Page 24 Danish Interpretation Systems User Manual VOX, voice activation mode, allows for the microphone units to be switched on automatically if speaking in the microphone or by pressing the microphone ON/OFF button. This is indicated by a red light in the ‘Speak’ lamp in the microphone unit. Pressing the microphone ON/OFF button again will turn the microphone off.
Page 25 Danish Interpretation Systems User Manual Interrupt Ability The Interrupt setting determines the microphone’s ability to interrupt another speaker if the maximum number of speakers is reached. The key is as follows: Use CU mode Not allowed: Cannot interrupt another speaker. <=: Can interrupt a speaker with the same speak priority or a speak priority which is less than own speak priority.
Page 26: Language Selection Functionality
Danish Interpretation Systems User Manual Automatic <= Speaker stand This unit can always turn on except if 8 units with ‘Speak priority”=5 open Also the serial number and type of all units Saving setting in CU 60xx connected to the CU 60xx at the time of saving the If individual settings are to remain in the units after configuration will be saved in the ‘Flash’...
Page 27: Normal Operation
Yes/Present (+) button can cast their votes to various subjects using the Pressing this button casts a ‘Yes’ vote or show the DCS 6000 Conference Units. user as ‘Present’ to the system. The voting functionality is only available when the...
Page 28: Normal Operation
Danish Interpretation Systems User Manual When the LED flashes together with the two other Cast a vote voting LED’s the user can press any of the voting When all the yellow voting LED’s flashes, the user buttons to cast a vote. can cast his vote, by pressing any of the three voting buttons.
Page 29: Chip Card Functionality
The Chip Card contains information like Login code Delegate ID, Login Code and Location ID, which the DCS 6000 system uses to identify the user of This is the password used to log the user into the the Conference Unit by getting the personal details system.
Page 30: Dcs Lan Connectors
Danish Interpretation Systems User Manual DCS LAN Connectors In addition to the connectors mentioned in the previous section the following connectors are available on all units: DCS-LAN connector Two RJ45 sockets are located at the back of the units for connecting to the previous unit (an IS 6132 Interpreter set, CS 6032 Channel Selector, DM 6xxx Delegate Unit, DC 6990 P Conference Unit, the CU 60xx Central Unit or any other unit with a...
Page 31: System Setup
CU 60xx Central Unit and the proper Settings termination are made, the CU can be switched ON. There are no settings to be done on the DCS 6000 After powering up the system, the light-ring in DCS conference units. The units are automatically...
Page 32 Danish Interpretation Systems Appendix Get the contrast adjustment tool, which has been shipped with your DCS 6000 Central Unit (see photo 1). A new adjustment tool can be ordered through your authorized DIS dealer. Order DIS p/n P0 45 00010.
Page 33 Danish Interpretation Systems Appendix Potentiometer Photo 4 Turn the adjustment tool until the required contrast setting is obtained. Do not use excessive force when turning the tool, as this will cause the potentiometer to be damaged. Carefully extract the adjustment tool from the adjustment hole. Manual 01 18 04467...
Page 34: Accessories
Danish Interpretation Systems Appendix Accessories The following accessories are available for use with the DCS 6000 Conference Units: GM 652x Gooseneck Microphones with XLR plug The gooseneck microphones are available in various lengths. To be connected to the XLR microphone...
Page 35 Danish Interpretation Systems Appendix DH 6001H Delegate Headphone This headphone is used with the built in channel selector. To be connected to the headphone connector Type Art No DH 6001H Delegate Headphone ..14 11 03054 DH 6021 Delegate Stereo Headphone This headphone is used with the DR 600x Receiver and DC 6990P.
Page 36 JB 6004 Junction Box......15 09 05758 EC 6000 cables Cat 5e Connection Cables (AWG24) The EC 6000 cables are used to connect the various units in the DCS 6000 system using the DCS-LAN connector: Type Art No EC 6001-..5 Connection Cable 0,5 m ..10 03 22500 EC 6001-01 Connection Cable 1 m ..10 03 23101...
Page 37: Appendix
Cabling - Loudspeaker output DIS type: CAT5 #2029 Speak 1 LED The DCS 6000 system uses CAT5, CAT5e or or according to Request 1 LED CAT6 FTP or STP cables with screened RJ45 the specific ON/OFF 1 button input connectors.
Page 38: Technical Specifications
Danish Interpretation Systems Appendix Technical specifications Digital Section General Microphone type..........Electret Cardioid Power requirement ..........24-48 V DC Microphone sensitivity ..........-22 DbV/Pa Power consumption............ 1W to 3W Max. SPL............125 dB (3% THD) Power supplied from CU 60xx / EX 6010 / PS 6000 Equivalent noise ..........App.
