- Page 1 DCS 6000 User Manual Digital Conference System IT 6108 Infrared Transmitter Danish Interpretation Systems...
- Page 2 Danish Interpretation Systems Operation manual Danish Interpretation Systems Copyright © 2003 No part of this publication may be reproduced or utilised in any form or by any means without permission in writing from the publisher.
-
Page 3: Table Of Contents
Danish Interpretation Systems Operation manual List of Contents Unit operating instructions ........7 List of Contents ............. 3 IT 6108 Infrared Transmitter ......7 Document version ..........3 Features ............7 Important............... 4 Description ............7 Compliancy ............4 User Controls, indications & connectors..7 Main lead wire ring ........... -
Page 4: Important
If a voltage conversion is required, consult harmful interference when the equipment is your DIS dealer or qualified personnel. operated in a commercial environment. The Should any liquid or solid object fall into the... -
Page 5: Repacking
For maximum protection, re-pack The individual units in the DCS 6000 system are the unit as originally packed from the factory. minimum covered by 12 months warranty against... -
Page 6: Description Of The System
EX 6010 Extension Power supply Features AO 6008 Audio Output box The DCS 6000 system is a “State of the Art” fully IT 6108 Infrared Transmitter digital integrated interpretation, discussion and voting system offering interpretation, language Interpreter and delegate equipment distribution, and conference microphone and voting facilities with attendance check with Chip Card ™. -
Page 7: Unit Operating Instructions
(IR test Power ON SWITCH diodes). On the front right-hand side of the IT 6108 there is Up to 20 DIS series IR15-xx Infrared Radiators a POWER switch for switching power ON. can be directly linked up. Power ON led... - Page 8 When using with IR15-06 and IR15-12 this switch has always to be in ON position. HF output 50 ohm Two BNC sockets for connecting to DIS series Rotary Switch RA15-xx Infrared Radiators. Up to 10 radiators can This switch is used for channel setting. This can be be directly connected to these sockets.
-
Page 9: System Settings
Danish Interpretation Systems Operation manual System settings The output channels are each set by use on the DIP Important: Do not set the rotary switch to Switch and the Rotary Switch as shown in the position B at any of the rotary switches where following figures. -
Page 10: Normal Operation
Danish Interpretation Systems Operation manual Self adhesive label The following self adhesive label is given a quick overview of the channel setting. The label is attached the User Manual. Please place the label as you wish. Switch 11 12 Channel 21 22 Channel Set unused channels to ”Off”... -
Page 11: System Setup
Danish Interpretation Systems Operation manual System Setup Typical schematics Manual 01 18 04452, Printed in Denmark, 02/2003 CHN... -
Page 12: Setting Of Audio Level On Ao 6008
Danish Interpretation Systems Operation manual Setting of audio level on AO 6008 When using the AO 6008 with the IT 6108 Infrared The correct level to be set on each connected Transmitter, the audio output level on the AO 6008 channel on the AO 6008 is –12db. -
Page 13: Appendix
DCS 6000 Appendix Appendix Technical appendix Cabling All cabling between the IT 6108 and RA15xx Infra Radiators are RG58 Coax cable. Connection between AO6108 and IT 6108: Accessories (not supplied) Audio Connection Cable: CA 9000 RG58 Connection Cable 1 m....10 02 13101 2m, 3pin XLR, male/female ........ -
Page 14: Technical Specifications
DCS 6000 Appendix Technical specifications Storage temperature IR-section ......-20 Deg C. to 60 Deg C. (10 to 80% humidity) Complies with the international standard IEC914 Distortion factor: ............< 1.0% Weight................5,5 kg Dimensions (W x H x D) ..425 (483) x 87 x 317 (357) mm Signal-to-noise ratio: .............
