Information
Operating, safety, and servicing instructions
Please read this operating, safety, and servicing instructions carefully before using
the pipe saw. Also store this instruction book somewhere accessible to everyone
using the pipe saw. In addition to these instructions, always follow the offi cial work,
health and safety regulations. The Exact PipeCut is meant for professional use only.

Technical data

Model
Voltage 1
Power
No-Load speed
Intermittent operation
Blade diameter
Mounting bore
Weight
Range of use Ø
Max. pipe wall steel
Max. pipe wall plastics
Protection class
Spindle lock
Speed preselection
Constant electronic control
Overload Protection
Reduced starting current
Vibration
LpA (sound pressure)
KpA (
sound pressure uncertanity
LWA (acoustic power)
KWA (
acoustic power uncertanity
The values given are valid for nominal voltages [U] of 230/240V. For lower voltage and models for
specifi c countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the
individual machines may vary. Only for power tools without reduced starting current: Starting cycles
generate brief voltage drops. Interference with other equipment/machines may occur in case of
unfavourable mains system conditions. Malfunctions are not to be expected for system impedances
below 0.36 ohm.
)
)
6
Pipecut 280
230 - 240 V / 50 Hz
1750 W
I (low) = 2900 /min, II (high) = 3900 /min
2,5 min ON / 7,5 min OFF (S3 25% 10 min)
165 mm (6,50")
62 mm (2,44")
9,0 kg (20 lbs)
40 mm – 280 mm (1,6"- 11")
10 mm (0,4")
38 mm (1,5")
/ II
Yes
Yes
Yes
Yes
Yes
2
2,84 m/s
90,6 dB(A)
3 dB(A)
103,6 dB(A)
3 dB(A)
english
