eXact PipeCut+Bevel 280 Pro Series Operating Instructions Manual

Hide thumbs Also See for PipeCut+Bevel 280 Pro Series:
Table of Contents

Advertisement

Quick Links

PipeCut+Bevel 280 Pro Series
These instructions are translation of the original instructions written in Finnish language.
All instructions are available on web-site: exacttools.com/manuals
Patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113
EN
Operating Instructions
360 Pro Series
460 Pro Series
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PipeCut+Bevel 280 Pro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for eXact PipeCut+Bevel 280 Pro Series

Summary of Contents for eXact PipeCut+Bevel 280 Pro Series

  • Page 1 English Operating Instructions PipeCut+Bevel 280 Pro Series 360 Pro Series 460 Pro Series These instructions are translation of the original instructions written in Finnish language. All instructions are available on web-site: exacttools.com/manuals Patents: US 7,257,895, JP 4010941, EP 1301311, FI 108927, KR 10-0634113...

  • Page 2: Declaration Of Conformity

    EN 55014-2, EN 61000-3-2, EN 61000-3-3 These instructions are translation of the original instructions written in Finnish For more information, please contact Exact Tools at the following address: The technical file is available at the address underneath: The person authorized to compile the technical file: Seppo Makkonen, chairman of the board (seppo.makkonen@exacttools.com)
  • Page 3 English FIGURE A Unlocking switch Power switch Power switch locking lever (in front of the switch) Blade guard cover Overload indicator light Moving blade-guard Adjusting screws Laser pointer box Adjusting wheel 10 Handle 11 Blade guard screw 12 Lock pin 13 Plate 14 Motor unit 15 Blade RPM speed control...
  • Page 4 English FIGURE A2...

  • Page 5: Table Of Contents

    Cutting result adjustment on Exact PipeCut+Bevel 280 / 360 / 460 Pro Series Installing and changing the blade Maintenance and servicing instructions Environment / disposal Guarantee / guarantee conditions Tips for using Exact PipeCut saws Extra equipment Theoretical cutting depths Instructions updated 18.10.2019...
  • Page 6 Safety instructions English Exact PipeCut+Bevel 280 / 360 / 460 Pro Series Voltage 230 V– 240 V / 50–60 Hz / 100 V–120 V 50–60Hz Power 2500 W– 230 V– 240 V / 15 А-100 V– 120 V No-load speed...

  • Page 7: Package Contents

    Package contents English Exact PipeCut+Bevel 280 / 360 / 460 Pro Series pipe cutting systems Package contents, please check that the package contains the following items: Exact PipeCut System Shoulder Bag Exact PipeCut+Bevel 280 / 360 / 460 pipe saw Pro Series Pipe Cutting supports 1 + 2 pcs.

  • Page 8: Safety Instructions

    Operating, safety and service instructions WARNING: If Exact PipeCut+Bevel 280 / 360 / 460 Pro Series Read these operating, safety and service tool is used with generator or extension cords, their instructions carefully before operating the pipe minimum requirements are as follows: saw.

  • Page 9: General Power Tool Safety Warnings

    Safety instructions English General power tool safety warnings 3 Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do WARNING: Read all safety warnings, not use a power tool while you are tired or under illustrations and specifications provided with this power tool.

  • Page 10: Cutting Procedures

    Safety instructions English 4 Cutting procedures DANGER: Keep hands away from cutting area and the blade. Keep your second hand on auxiliary handle, or motor housing. If both hands are holding the saw, they cannot be cut by the blade. b) Do not reach underneath the workpiece.
  • Page 11 Safety instructions English d) Always observe that the lower guard is covering the blade before placing the saw down on bench or floor. An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware of the time it takes for the blade to stop after switch is released.

  • Page 12: Intended Use

    Safety instructions English Further safety instructions Intended Use The pipe saw must never be used in the following cases, if: PipeCut+Bevel 280 / 360 460 Pro Series There is water or another liquid, explosive gases or  poisonous chemicals inside the pipe to be cut. PipeCut+Bevel 280 / 360 / 460 Pro Series pipe saw The power switch is faulty.

  • Page 13: Operation

    Operation English Exact PipeCut+Bevel Pro Series pipe cutting system operation instructions Pull the lower blade guard, washer, spring Cut+Bevel Pro Series features and bushings of the axle. Note the locations of bushings and spring. Bevel depth and width is adjusted with depth Insert bushings to the lower blade guard to adjustment roller (Fig.

  • Page 14: Setting The Pipe On Supports

    Operation English Make sure that lower blade guard is installed with the Cut+Bevel Diamond disc. Regular blade cover does not have big enough opening for the FIGURE B1 Cut+Bevel Diamond disc. WARNING: Regular lower blade cover must be installed if saw is used with regular saw blade with cutting teeth.

  • Page 15: Piercing The Pipe Wall

    Operation English Piercing the pipe wall FIGURE Grip the gripper firmly with your right hand and place your left foot on top of the pipe approximately 50 cm from the pipe saw. Turn the saw until it leans slightly forward (Figure F). When starting the motor, first of all release the power-switch locking lever (Fig D/1) and push the power switch all the way down (Fig D/2).

  • Page 16: Explanation If Indicator Lights

    Operation English Overload protector and blade RPM speed control FIGURE The saw has a two-speed blade RPM speed control (Fig A / 15). When cutting stainless or acid-proof steel use the lower RPM setting l. When cutting other materials use the faster RPM setting ll. The saw also has an overload protector which displays electric motor loading with three indicator lights (Fig A / 5).
  • Page 17 Operation English Saw has moved from left to right...
  • Page 18 Operation English Cutting result adjustment for models Exact PipeCut+Bevel 280 / 360 / 460 Pro Series FIGURE Within the gripping devices of these models there are eight control wheels. One of them is the adjustment wheel (FIGURE A / 9). Please note that adjustment by...

  • Page 19: Installing And Changing The Blade

    Operation English Maintenance and servicing instructions CAUTION! If the motor unit is adjusted with the laser, the gripping device must be attached to the pipe with Remove the power plug from the socket before normal tension. This ensures that the saw fastening servicing or cleaning the pipe saw.
  • Page 20 Warranty Do not overload the saw while working without Term, at our discretion we will repair the Exact PipeCut interruption. The pipecut will overheat and metal parts Saw or supply an entirely new or factory reconditioned can become very hot.
  • Page 21 Factors influencing blade lifespan: Blade suitability Pipe material  Blade suitability for the pipe material  Exact TCT: Suitable for cutting steel and all kinds of Correct motor speed setting  plastic pipe material Pipe wall thickness  Exact Cermet: Suitable for cutting stainless steel Feed rate ...
  • Page 22 39,2 46,7 51,7 Max. pipe wall thicknesses in different pipe materials, which can be cut by Exact PipeCut+Bevel 280 / 360 / 460 Pro Series machines European model 230V / 2500W Steel pipes Max.pipe wall thickness 20 mm / 0.78”...
