Primary Harness (H1) Wiring Diagram; Primary Harness Wire Descriptions - Directed Electronics 4400 Installation Manual

Primary Harness (H1), Wire Connection
Guide

Primary Harness (H1) Wiring Diagram

___
ORANGE
H1/1
___
WHITE
H1/2
___
WHITE/BLUE
H1/3
___
BLACK/WHITE
H1/4
___
GREEN
H1/5
___
BLUE
H1/6
___
VIOLET
H1/7
___
H1/8 BLACK
___
H1/9 OPEN
___
H1/10 BROWN
___
H1/11
RED
___
H1/12
RED/WHITE

Primary Harness Wire Descriptions

H1/1 ORANGE (-) Ground-When-Armed Output
This wire supplies a (-) 500 mA ground as long as the system is armed. This output ceases as soon
as the system is disarmed. The orange wire is pre-wired to control the 8618 starter kill relay.
NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window
© 2003
Directed Electronics, Inc.
(-) 500 mA Armed Output
(+)/(-) Selectable Light Flash Output
(-) Remote Start Activation Input
(-) 200 mA Domelight Supervision Output
(-) Door Trigger Input, Zone 3
(-) Multiplexed Input, Zone 4
(+) Door Trigger Input, Zone 3
(-) Chassis Ground Input
(+) Siren Output
(+) Constant Power Input
(-) 200 mA Channel 2 Output
No Wire
7
