Directed Electronics 480XP Owner's Manual

Directed Electronics 480XP Owner's Manual

Dei python 480xp car alarms: owners guide
Hide thumbs Also See for 480XP:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
4 4 8 8 0 0 X X P P
➤
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 480XP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed Electronics 480XP

Summary of Contents for Directed Electronics 480XP

  • Page 1 4 4 8 8 0 0 X X P P ➤ O O w w n n e e r r ’ ’ s s G G u u i i d d e e...
  • Page 3 l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y Directed Electronics, Inc.
  • Page 4 CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE.

  • Page 5: Table Of Contents

    t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s s s t t a a n n d d a a r r d d t t r r a a n n s s m m i i t t t t e e r r c c o o n n f f i i g g u u r r a a t t i i o o n n ................2 2 w w h h a a t t i i s s i i n n c c l l u u d d e e d d .
  • Page 6 s s t t a a n n d d a a r r d d t t r r a a n n s s m m i i t t t t e e r r c c o o n n f f i i g g u u r r a a t t i i o o n n controls the A A r r m m function.
  • Page 7 w w h h a a t t i i s s i i n n c c l l u u d d e e d d ➤ The control module ➤ An XHF receiver/antenna ➤ A pair of four-button transmitters ➤...

  • Page 8: System Maintenance

    ➜ system maintenance The system requires no specific maintenance. Your remote is powered by a small, lightweight 3-volt lithium battery that will last approximately one year under normal use. When the battery begins to weaken, operating range will be reduced and the LED on the remote will dim.

  • Page 9: Caution

    ➜ caution This product is designed for fuel injected, automatic transmis- sion vehicles only. Use of this product in a standard transmission vehicle is dangerous and contrary to the product's intended use. t t r r a a n n s s m m i i t t t t e e r r f f u u n n c c t t i i o o n n s s The receiver uses a computer-based learn routine to learn the transmitter buttons.

  • Page 10: Warning! Safety First

    less than one second before arming or disarming. An optional auxiliary function, such as trunk release, can be controlled by pressing this button for 1.5 seconds.) The auxiliary output controls __________________________. Button The panic feature is controlled by pressing this button for one second.* Buttons The remote start function of your system is controlled by...
  • Page 11 When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must be disabled using the installed toggle switch. It is the user's sole responsibility to properly handle and keep out of reach from children all remote control transmitters to assure that the system does not unintentionally remote start the vehicle.

  • Page 12: Locking/Arming

    start module by performing the Safety Check outlined in the product installation guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit test, the remote start unit has not been properly installed. The remote start module must be removed or the installer must properly reinstall the remote start system so that the vehicle does not start in gear.

  • Page 13: Unlocking/Disarming

    The system can also be programmed to arm the optional Failsafe ® Starter Kill automatically (called Passive Mode). If the system has ® been programmed for Passive Mode, the Failsafe Starter Kill will automatically activate 30 seconds after the ignition has been turned off.

  • Page 14: Disabling The System Without A Transmitter

    ➜ disabling the system without a transmitter If your remote transmitter is lost or damaged, you can manually override the system. To do this, you must have the vehicle's igni- tion key and know where the Valet ® switch is located. Be sure to check with the installer for the location of the Valet ®...

  • Page 15: Silent Mode

    To enter or exit Valet ® Mode: 1. Turn the ignition on. 2. Turn the ignition off. 3. Press and release the Valet® switch within 10 seconds. DRW-35 The status LED will light steadily if you are entering Valet ® Mode and will turn off if you are exiting Valet ®...

  • Page 16: Remote Start

    seconds. To stop Panic Mode at any time, press on the transmitter again. note: In order for Panic Mode to be effective, the vehicle’s horn (or optional siren) as well as the vehicle's parking lights must be connected. ➜ remote start This feature allows you to remotely start and run your vehicle for a programmable period of time.
  • Page 17 4. Once the vehicle has started, it will run for the pre-program- med period of time (either 12, 24, or 60 minutes - see Programming Options section of this guide) or until a shut- down input is triggered. i i m m p p o o r r t t a a n n t t ! ! It is unsafe to operate a vehicle’s motor in a garage or other closed off area.

  • Page 18: Valet Take-Over

    To shut down the remote start and turn off the engine: ➤ Step on the brake pedal, or ➤ Press for one second. ➜ valet take-over The Valet ® Take-Over feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate controls on.
  • Page 19 important! This feature must only be used in open areas, never in an enclosed area such as a garage. To enter Timer Mode: 1. Start the vehicle by pressing and releasing 2. Press and release 3. Within two seconds press and release again.

  • Page 20: Starter Anti-Grind Circuitry

    s s a a f f e e t t y y f f e e a a t t u u r r e e s s This system has several important safety features to ensure proper operation of the motor and prevent accidental damage to the engine or its components.

  • Page 21: Over And Under Rev Protection

    ➜ over and under rev protection The system monitors the engine speed and will automatically shut the engine off if the RPMs rise above or fall below the programmed levels. This feature prevents damage to the motor due to fuel delivery system failures or other problems which may cause the engine to race.
  • Page 22 c c o o d d e e h h o o p p p p i i n n g g The receiver and transmitters each use mathematical formulas called algorithms to change their codes each time the transmitter is used.
  • Page 23 note: Owner Recognition cannot be programmed with- out a Directed Bitwriter and the necessary software. Check with your dealer for more information. r r a a p p i i d d r r e e s s u u m m e e l l o o g g i i c c This Directed system will store its current state to non-volatile memory.
  • Page 24 p p r r o o g g r r a a m m m m i i n n g g o o p p t t i i o o n n s s Programming options control your system's normal, operational set-up.
  • Page 25 g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s The “brain” of your system. Usually hidden under Control Unit: the dash area of the vehicle.
  • Page 26 c c o o n n v v e e n n i i e e n n c c e e e e x x p p a a n n s s i i o o n n s s Listed below are some of the many expansion options available for use with your system.
  • Page 27 two windows down by using the transmitter. The 530T will roll two windows both up and down. The 530T also provides one touch switch operation. For added security, your system can Progressive Door Unlocking: be configured to unlock the driver’s door only, leaving the passenger doors locked.

  • Page 29: Quick Reference Guide

    QUICK REFERENCE GUIDE To lock/arm using your remote ä To arm the system press for one second. The doors will lock (if connected). The LED will begin to flash. The Failsafe® Starter Kill will prevent the vehicle’s starter from cranking if it has been installed. The vehi- cle’s horn (if connected) will honk and the parking lights will flash once to confirm arming of the system.
  • Page 30 © 2002 directed electronics, inc.
  • Page 31 The company behind this system is Directed Electronics, Inc. Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DIRECTED is ISO 9001 registered.
