Model 425
Owner's Guide
G425A
Downloaded from: http://www.guardianalarms.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 425 and is the answer not in the manual?

Questions and answers

Summary of Contents for Directed Electronics 425

  • Page 1 Model 425 Owner’s Guide G425A Downloaded from: http://www.guardianalarms.net...
  • Page 3: Limited Lifetime Consumer Warranty

    Limited Lifetime Consumer Warranty Directed Electronics, Inc. ("DEI ® ") promises to the original purchaser to repair or re- place with a comparable reconditioned model any DEI unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and ac-...
  • Page 4 Your full name and address Authorized dealer's company name and address Type of alarm installed Year, make, model and color of the automobile Automobile license number Vehicle identification number All security options installed on automobile Installation receipts 1999 Directed Electronics, Inc. ©...
  • Page 5: Table Of Contents

    Quick Reference Guide (Removable) ....... 21 1999 Directed Electronics, Inc. ©...
  • Page 6: Standard Configuration

    Standard Configuration 1999 Directed Electronics, Inc. ©...
  • Page 7: What Is Included

    3-volt battery, type 2032, that lasts ap- proximately one year under normal use. When the battery weakens, the LED on the remote will dim and flash quickly whenever it is used. 1999 Directed Electronics, Inc. ©...
  • Page 8: Your Warranty

    The transmitter initially comes programmed with the Standard Con- figuration, but may also be customized by an authorized dealer. Unless otherwise specified, all instructions in this manual assume opera- tion using the Standard Configuration. 1999 Directed Electronics, Inc. ©...
  • Page 9: Standard Configuration

    An optional auxiliary function, such as trunk release, is controlled by pressing and holding for 1.5 seconds. The auxiliary output controls _____________________________. Button Panic Mode is activated by pressing and holding for one second. 1999 Directed Electronics, Inc. ©...
  • Page 10: Using Your System

    (called Passive Arming). Once the 30-second countdown period initiates, the status LED will flash twice as fast as it does when the system is armed. After 20 seconds, the siren will chirp once 1999 Directed Electronics, Inc. ©...
  • Page 11 Turning on the ignition key triggers the same two-stage Progressive Response as opening a door. If installed, the Failsafe ® Starter Kill Relay (optional feature) pre- vents the vehicle’s starter from cranking. 1999 Directed Electronics, Inc. ©...
  • Page 12: Disarming

    IMPORTANT: The Valet switch can be programmed to respond to 1-5 presses for the disarm function. You must check with the installer to ver- ify the programming for your individual unit. LOCATION OF VALET SWITCH_____________________________ 1999 Directed Electronics, Inc. ©...
  • Page 13: Silent Mode

    Valet Mode prevents your system from arming and triggering ei- ther automatically or with the transmitter. In Valet Mode, all convenience functions (door locks, trunk release, etc.) will remain operational. This feature is useful when washing or servicing your vehicle. 1999 Directed Electronics, Inc. ©...
  • Page 14: Remote Valet

    Here’s how it works: If the alarm is triggered by the same sensor or switch three times within a 60 minute period, your system inter- prets this pattern of triggers as false alarms. After the third trigger, 1999 Directed Electronics, Inc. ©...
  • Page 15: Diagnostics

    If the security system is armed at the same time that an input is active (door opening, sensor triggering, etc.), you will hear one chirp to indicate arming and a second chirp to indicate Bypass Notifica- tion. A Bypass Notification chirp means that the system ignores the 1999 Directed Electronics, Inc. ©...
  • Page 16: Disarming Diagnostics

    A zone is represented by the number of LED flashes used by the sys- tem to identify a particular type of input. Standard input assignments are listed in the following table, along with spaces to write in any optional sensors or switches that have been installed. 1999 Directed Electronics, Inc. ©...
  • Page 17: Code Hopping

    To resynchronize the transmitter, sim- ply press several times within range of the vehicle. The system will automatically resynchronize and the transmitter will re- spond normally. 1999 Directed Electronics, Inc. ©...
  • Page 18: Owner Recognition

    Valet Mode when the battery is dis- connected, it will still be in Valet Mode when the battery is reconnected. This applies to all system features, including arm- ing, disarming, and Valet Mode. 1999 Directed Electronics, Inc. ©...
  • Page 19: Multi-Vehicle Operation

    Your security system has some options that may require extra parts and labor. One of these options, Progressive Unlocking, configures the system so that when you press to disarm, only the dri- ver’s door unlocks. Pressing again within 15 seconds unlocks the remaining doors. 1999 Directed Electronics, Inc. ©...
  • Page 20: Programming Options

    Your dealer can eliminate any of these tones, resulting in a unique, easily iden- tifiable siren sound. The chirps can be programmed for either full volume or six decibels quieter than the full alarm blast. 1999 Directed Electronics, Inc. ©...
  • Page 21: Security & Convenience Expansions

    This option is available only for au- tomatic transmission, fuel-injected gasoline vehicles. Power Window Control: You can add various power window control features with either the 529T Power Window Roll-Up Module or the 530T Window Automation System. 1999 Directed Electronics, Inc. ©...
  • Page 22: Glossary Of Terms

    A Triggered Response consists of the siren sounding and the parking lights flashing for 30 seconds. Valet Switch: A small, push-button switch mounted inside the ve- hicle, at a location determined by the installer. This switch is used 1999 Directed Electronics, Inc. ©...
  • Page 23 Zone: A zone is a separate input that the alarm can recognize as unique. Each input to the system is connected to a particular zone. Two or more inputs may share the same zone. 1999 Directed Electronics, Inc. ©...
  • Page 24 Notes 1999 Directed Electronics, Inc. ©...
  • Page 25: Quick Reference Guide (Removable)

    Press and hold for one second. To exit Panic Mode Press , or To activate Silent ® Mode Press briefly before arming or disarming. The confirmation chirp(s) will be eliminated for that one operation only. 1999 Directed Electronics, Inc. ©...
  • Page 28 20 patents in the field of advanced electronic technology, DEI is ISO 9001 regis- tered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 477-1372 for more information about our products and services.
