as a shut-down.

Testing the Neutral Safety Switch

1. Make sure there is adequate clearance to the front and rear of the vehicle because it may move
slightly.
2. Make sure the hood is closed and there are no remote start shut-downs active.
3. Set the emergency brake.
4. Turn the key to the "run" position, this will release the shifter.
5. Place the car in drive (D).
6. Place your foot directly over the brake pedal, but do not depress it. Be ready to step on the brake
if the starter engages.
7. Activate the remote start system.
8. If the starter engages, immediately depress the brake to shut the remote start system down. If
the starter does not engage, no additional safety system is required.
If the starter engages while testing, refer to technical document #1008 (Neutral Safety Update). It
is available to authorized dealers only from the technical resources listed at the beginning of this
manual.
IMPORTANT! Once the interface is complete, attempt to remote start the vehicle with
the door closed and the key in the ignition. The vehicle should not start. If it does,
recheck the connections.
Door Lock Harness (H4),
Wire Connection Guide
___
Green
H4/A
___
Empty
H4/B
___
Blue
H4/C
© 2003
Directed Electronics, Inc.
(-) Lock, (+) Unlock Output
Unless Using 451M
(-) Unlock, (+) Lock Output
19
