Control Mode Selections
There are four control modes for the power supply: NORMAL, PRESET, SET and REMOTE CONTROL
modes. Slide the Mode Selection Switch (8) to the desired Mode. The power supply is factory
preset to Normal Mode with maximum current level CC.
Normal Mode
This is the factory default mode; the power supply output Voltage and Current are controlled by
the dual action gain knobs.
1.
Push the knobs to toggle the coarse and fine tuning, notice the subtle changes in
brightness of the related LED.
2.
Adjust the knobs to the desired values using coarse and then fine tuning.
3.
To check the preset current level, turn the Current Knob lightly in any direction.
4.
The display will resume its normal brightness after a few seconds to re‐affirm the
adjustment.
Nota: La corrente nominale totale (Aux. + principale) è 10A
Preset Mode
1.
In this mode, the Rear Control Light is ON to indicate that the panel V & I controls are de‐
activated.
2.
There are three preset outputs P1/ P2/ P3 available using the Recall Selection Switch (9)
3.
The preset values are factory set as shown in the table below.
4.
The user can change these output settings; please refer to the next paragraph.
Set Mode
Enter the Set Mode by pushing Switch (8) to the Set Mode slot; the power supply is now ready to
be preset.
To define the preset output P1/ P2/ P3
1.
Move the Recall Switch (9) to position P1, P2 or P3
2.
Adjust the front panel voltage control knob to set the desired voltage value
3.
Adjust the front panel current control knob to set the desired current limit value
4.
Repeat the procedure for the remaining recall locations P1, P2, P3 if desired.
5.
Move Mode Switch (8) from Set to Preset position to confirm the settings.
Set Mode Notes:
All presets are saved after the power supply has been switched off. Always check the output
voltage of the Preset before connecting to a Load. To check the preset values:
1.
Move the Mode Switch (8) to the Preset position and then set the Recall Switch (9) to P1,
P2 or P3.
2.
The V and I settings for the corresponding RECALL P1, P2, P3 memories will be shown on
the panel meter.
Recall No.
P1
P2
P3
Output Voltage
5V
13.8V
55V
5
Output Current
Maximum
Maximum
Maximum
DCP60‐EU‐IT v1.4 9/13
