Aydin Displays VFP20 User Manual

20.1 inch amlcd flat panel color monitor
Hide thumbs Also See for VFP20:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
USER'S GUIDE
for the
Model VFP20
20.1 INCH AMLCD FLAT PANEL COLOR MONITOR

Rack Mount

Panel Mount
VESA Mount
Document # 150-VF20-002 Rev 2
January 2014
1 Riga Lane, Birdsboro, PA 19508 USA
Telephone: 610-404-7400 * Fax: 610-404-8190 *
www.aydindisplays.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFP20 and is the answer not in the manual?

Questions and answers

Related Manuals for Aydin Displays VFP20

Summary of Contents for Aydin Displays VFP20

  • Page 1: Rack Mount

    USER’S GUIDE for the Model VFP20 20.1 INCH AMLCD FLAT PANEL COLOR MONITOR Rack Mount Panel Mount VESA Mount Document # 150-VF20-002 Rev 2 January 2014 1 Riga Lane, Birdsboro, PA 19508 USA Telephone: 610-404-7400 * Fax: 610-404-8190 * www.aydindisplays.com...
  • Page 2 Aydin Displays reserves the right to modify or revise the content of this manual. It is further understood that in consideration of the receipt or purchase of this...
  • Page 3 PRODUCT SAFETY PRECAUTIONS The socket-outlet of power supply shall be installed near the equipment and shall be easily accessible. ♦ Follow all warnings and instructions marked on the display. ♦ Do not attempt to service this display yourself. There are no user replaceable parts inside and removing ♦...
  • Page 4 Thank you for purchasing the Aydin Displays VECTOR Display. This carton contains the items listed below:  VFP 20 LCD Display  Power cord  VGA Video Cable HD15(M) to HD15(M)  CD-ROM with this User’s Guide  Mounting hardware (if applicable) ...

  • Page 5: Table Of Contents

    Table of Contents Introduction ...................... 6 Specifications ....................6 LCD......................6 Inputs ......................6 2.2.1 Power....................6 2.2.2 DVI..................... 7 2.2.3 Analog R-G-B ..................7 2.2.4 Composite Video ................7 2.2.5 S-Video ....................8 2.2.6 RS232....................8 Front Panel Buttons/On-Screen Display ............8 Front Panel Buttons ..................

  • Page 6: Introduction

    Introduction The Model VFP20 AMLCD Monitor is a 20.1” diagonal display with a native resolution of 1600 x 1200 (UXGA) pixels. Inputs are provided for DVI-D, VGA, Composite (NTSC, PAL or SECAM) Video, and S-Video (NTSC, PAL or SECAM). Generally all VESA compatible video formats are supported.

  • Page 7: Dvi

    2.2.1.2 24 VDC or 28 VDC input Connector: Monitor: Molex 42179 Plug Housing Power Cord: Molex # 03-12-1026 Connector with two # 18-12-1222 Female Terminals for 16-18 AWG Wire Pin out: Pin 1 is +VDC (Red Wire) Pin 2 is Power Ground (Black Wire) Input Voltage: 19 –...

  • Page 8: S-Video

    An RS232 interface is provided for remote control. A Windows compatible application program is available from the factory that enables a remote PC to display and manipulate the monitor’s On-Screen-Displays. Contact Aydin Displays for information. Front Panel Buttons/On-Screen Display 3.1 Front Panel Buttons Press SELECT to display the On-Screen-Display (OSD).

  • Page 9: Input Select - Main Picture Channel

    3.1.1 Input Select – Main Picture Channel Selects the input source for the Main Picture. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs Component Color Adjustment PIP Mode √DVI Video Settings S-Video Scaling Adjustments Composite Video System Settings 3.1.2 Input Select –...

  • Page 10: Input Select - Pip Mode

    3.1.3 Input Select – PIP Mode Selects for a single Main Picture, a Picture in Picture (PIP) or Side by Side in the same fixed size. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs Color Adjustment PIP Mode √Off Video Settings PIP Channel...

  • Page 11: Input Select - Pip Ver. Position

    3.1.5 Input Select - PIP ver. Position Adjusts vertical position of PIP. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs Color Adjustment PIP Mode Video Settings PIP Channel Scaling Adjustments PIP hor. Position PIP ver. Position Swap Main & PIP 3.1.6 Input Select –...

  • Page 12: Image Adjustments

    Image Adjustments The adjustments provided on the Image Adjustments sub-menu only affect the Main Picture channel, not the PIP. Auto Adjust is pattern sensitive and may not give consistent results. Main Menu Input Select Auto Adjust Image Adjustments Color Adjustment Clock Video Settings Phase...

  • Page 13: Color Adjustment - Advanced

    3.3.1 Color Adjustment – Advanced Main Menu Input Select Gamma Image Adjustments Color Space Color Adjustment Color Temp. Video Settings Scaling Adjustments Green System Settings Blue Video Settings This sub-menu is only available when S-Video or Composite Video is selected as the Main Picture Channel input.

  • Page 14: Video Settings - Decoder Settings

    3.4.1 Video Settings – Decoder Settings Main Menu Input Select Video Brightness Image Adjustments Video Contrast Color Adjustment Video Saturation Video Settings Video Hue Scaling Adjustments Video Sharpness System Settings Scaling Adjustments The adjustments provided on the Scaling Adjustments sub-menu only affect the main Picture channel, not the PIP.

  • Page 15: Scaling Adjustments - Scaling Mode

    3.5.1 Scaling Adjustments - Scaling Mode The Scaling Modes are Expand, Stretch, Aspect and 1:1. Expand is the default. 3.5.2 Scaling Adjustments - Picture Flip Allows you to flip the Main Picture horizontal or vertical. 3.5.3 Scaling Adjustments – Zoom and Pan Allows you to magnify and display any portion of the main picture.

  • Page 16: System Settings - Osd Orientation

    3.6.4 System Settings – OSD Orientation The OSD can be rotated 90°, or flipped horizontally or vertically. 3.6.5 System Settings – OSD Language The OSD can be displayed in various languages. Default is English. Maintenance Preventive Maintenance The window and exterior surfaces may be cleaned with isopropyl alcohol followed by distilled water rinse, applied with a soft cloth to avoid scratching the anti-reflective coating of the viewing window.
  • Page 17 Systems. Before installing a new driver, please determine which of these technologies is installed and remove any old drivers to prevent software conflicts. If you require further assistance, please contact Aydin Displays’ Customer Service at 610- 404-7400 Based on your model’s configuration, refer to this chart to download the applicable driver:...
  • Page 18 VECTOR 20 SPECIFICATIONS: Visual Performance: Diagonal: 20 inch TFT Active-Matrix LCD Active Display Area: Horiz.: 408 mm (16.06”) Vert.: 306 mm (12.05”) Pixel Pitch: 0.255 mm Luminance: 300cd/m (typical) Contrast Ratio: 800:1 (typical) º Viewing Angle: +/-89 all directions at CR >10 (typical) Response Time: 16ms T (typical)
  • Page 19 Input Connectors: Digital: Single-Link DVI-D. Supports up to 160 Mhz operation. Analog R-G-B: HD15 female (Standard VGA pin-out) Supports up to 165 MHz (UXGA 60 Hz) Composite Video: RCA Jack Supports NTSC, PAL or SECAM S-Video: 4-Pin mini-DIN (Standard S-Video pin-out) Supports NTSC, PAL or SECAM Environmental: Operating Temperature:...
  • Page 20 20 of 21 298-7170 Rev 2...
  • Page 21 21 of 21 298-7170 Rev 2...
