Page 1: Color Monitor
User’s Guide Model VFP20 (Ver 2) 20.1-INCH AMLCD FLAT PANEL COLOR MONITOR Document No. 150-VF20-002 Rev. A, June 2009... - Page 2 Aydin Displays reserves the right to modify or revise the content of this manual. It is further understood that in consideration of the receipt or purchase of this...
- Page 3 ♦ Use the specified cables with the VFP20 display so as not to interfere with radio and television reception. ♦ Use the supplied power cable or equivalent to ensure FCC compliance ♦...
- Page 4 WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH VOLTAGE COMPONENTS INSIDE.
- Page 5 PRODUCT SAFETY PRECAUTIONS ♦ The socket-outlet of power supply shall be installed near the equipment and shall be easily accessible. ♦ Follow all warnings and instructions marked on the display. ♦ Do not attempt to service this display yourself. There are no user replaceable parts inside and removing the display cover or back will expose you to dangerous voltage or other risks.
- Page 6 Thank you for purchasing the Aydin Displays VECTOR Display. This carton contains the items listed below: ♦ VFP20 LCD Display ♦ Power cord ♦ Video signal cable (HD15 male HD15 male) ♦ Capacitive Touch Option Interface Cable (if applicable) ♦...
-
Page 7: Table Of Contents
Table of Contents INTRODUCTION......................... 1 SPECIFICATIONS........................1 LCD............................1 ............................. 1 NPUTS 2.2.1 Power ..........................1 2.2.2 DVI ..........................2 2.2.3 Analog R-G-B........................2 2.2.4 Composite Video ......................2 2.2.5 S-Video ..........................2 2.2.6 RS232 ..........................2 FRONT PANEL BUTTONS/ON-SCREEN DISPLAY ............. 3 ...................... -
Page 8: Introduction
Introduction The Model VFP20 AMLCD Monitor is a 20.1-IN diagonal display with a native resolution of 1600 x 1200 (UXGA) pixels. Inputs are provided for DVI-D, VGA, Composite (NTSC, PAL or SECAM) Video, and S-Video (NTSC, PAL or SECAM). Generally, all VESA compatible video formats are supported. -
Page 9: Dvi
Supports NTSC, PAL or SECAM 2.2.6 RS232 An RS232 interface is provided for remote control. A Windows compatible application program is available from the factory that enables a remote PC to display and manipulate the monitor’s On- Screen-Displays. Contact Aydin Displays for information. 150-VF20-002(A).doc... -
Page 10: Front Panel Buttons/On-Screen Display
Front Panel Buttons/On-Screen Display 3.1 Front Panel Buttons Press SELECT to display the On-Screen-Display (OSD). Use the ADJUST+ and ADJUST- to move the cursor to the desired menu selection and press SELECT to access the adjustment or function. With the EXIT button you can exit the current function and go back to the previous menu point. Main Menu The OSD always starts with the Main Menu. -
Page 11: Input Select - Main Picture Channel
3.1.1 Input Select – Main Picture Channel Selects the input source for the Main Picture. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs Component √DVI Color Adjustment PIP Mode Video Settings S-Video Scaling Adjustments Composite Video System Settings 3.1.2 Input Select –... -
Page 12: Input Select - Pip Mode
3.1.3 Input Select – PIP Mode Selects for a single Main Picture, a Picture in Picture (PIP) or Side by Side in the same fixed size. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs √Off Color Adjustment PIP Mode Video Settings PIP Channel... -
Page 13: Input Select - Pip Ver. Position
3.1.5 Input Select - PIP ver. Position Adjusts vertical position of PIP. Main Menu Input Select Main Picture Channel Image Adjustments Scan Inputs Color Adjustment PIP Mode Video Settings PIP Channel Scaling Adjustments PIP hor. Position PIP ver. Position Swap Main & PIP 3.1.6 Input Select –... -
Page 14: Color Adjustment
Color Adjustment The adjustments provided on the Color Adjustment sub-menu only affect the Main Picture Channel, not the PIP, and is only available when VGA is selected for the Main Picture Channel input. It is recommended that all Color Adjustment parameters be left at factory default. Auto Color Adjust is pattern sensitive and may not give consistent results. -
Page 15: Video Settings
Video Settings This sub-menu is only available when S-Video or Composite Video is selected as the Main Picture Channel input. Main Menu Input Select Motion Processing Image Adjustments Sharpness Color Adjustment Film Mode Video Settings Noise Reduction Scaling Adjustments Mpeg Processing System Settings Decoder Settings 3.4.1 Video Settings –... -
Page 16: Scaling Adjustments
Scaling Adjustments The adjustments provided on the Scaling Adjustments sub-menu only affect the main Picture channel, not the PIP. Main Menu Input Select Scaling Mode Image Adjustments Picture Flip Color Adjustment Video Settings Zoom Scaling Adjustments Hor. Pan System Settings Ver. -
Page 17: System Settings
System Settings Main Menu Input Select OSD Timeout Image Adjustments OSD Hor. Pos. Color Adjustment OSD Ver. Pos Video Settings OSD Blend Scaling Adjustments OSD Orientation System Settings OSD Language Reset to Default 3.6.1 System Settings - OSD Timeout OSD Timeout default is 30-seconds. Time should be set between 5 and 60-seconds. Setting the value to 0 will cause the OSD to permanently stay on. -
Page 18: Maintenance
If the Yellow NO SYNC indicator is lit, most likely the monitor is not receiving a video input or that video input is not selected as the Main Picture Channel Input. (See section 3.1.1) 4.4 VGA Cable The recommended VGA cable is Aydin Displays part number 123-098-001. 150-VF20-002(A).doc... -
Page 19: Touch-Screen Driver Information
Before installing a new driver, please determine which of these technologies is installed and remove any old drivers to prevent software conflicts. If you require further assistance, please contact Aydin Displays’ Customer Service at 610-404-7400 Based on your model’s configuration, refer to this chart to download the applicable driver:... -
Page 20: Vector 20 Specifications
Vector 20 Specifications Visual Performance: Diagonal: 20 inch TFT Active-Matrix LCD Active Display Area: Horiz.: 408 mm (16.06-in) Vert.: 306 mm (12.05-in) Pixel Pitch: 0.255 mm Luminance: 300cd/m2 (typical) Contrast Ratio: 800:1 (typical) Viewing Angle: +/-89º all directions at CR >10 (typical) Response Time: 16ms Tr + Tf (typical) Resolutions Supported:... -
Page 21: Input Connectors
Input Connectors: Digital: Single-Link DVI-D. Supports up to 160 MHz operation. Analog R-G-B: HD15 female (Standard VGA pin-out) Supports up to 165 MHz (UXGA 60 Hz) Composite Video: RCA Jack Supports NTSC, PAL or SECAM S-Video: 4-Pin mini-DIN (Standard S-Video pin-out) Supports NTSC, PAL or SECAM Environmental: Operating Temperature:... -
Page 22: Outline Drawings
Outline Drawings 150-VF20-002(A).doc... - Page 23 150-VF20-002(A).doc...
- Page 24 150-VF20-002(A).doc...
