- Page 1 1 Riga Lane, Birdsboro, PA 19508 USA ♦ Phone: (610) 404-7400 ♦ Fax: (610) 404-8190 User’s Guide VFP15 FAMILY 15” FLAT PANEL DISPLAY Document No. 150-VFP5-003 Rev. A, May 2004...
- Page 2 Aydin Displays reserves the right to modify or revise the content of this manual. It is further understood that in consideration of the receipt or purchase of this manual, the...
-
Page 3: Federal Communications Commission Requirements
FEDERAL COMMUNICATIONS COMMISSION REQUIREMENTS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 4 WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
-
Page 5: Product Safety Precautions
PRODUCT SAFETY PRECAUTIONS ♦ The socket-outlet of power supply shall be installed near the equipment and shall be easily accessible ♦ Follow all warnings and instructions marked on the display ♦ Do not attempt to service this display yourself. There are no user replaceable parts inside and removing the display cover or back will expose you to dangerous voltage or other risks. - Page 6 Thank you for purchasing the Aydin Displays VECTOR Display. This carton contains the items listed below: ♦ VFP15 LCD Display ♦ Power cord ♦ 15-pin VGA HD15 to HD15 Video Cable ♦ Mounting hardware (if applicable) ♦ Product CD containing: –...
-
Page 7: Display Adjustments
DISPLAY ADJUSTMENTS: If you have any problems connecting, setting-up, or operating the display, please refer to the Troubleshooting section of this guide. Connect one end of the video cable to the HD15 connector on the rear of the display and the other end to the HD15 on the computer. -
Page 8: Image Controls
AUTO ADJUST: Automatically adjusts the Image Position, the Horizontal Size and Fine setting. IMAGE CONTROLS: LEFT/RIGHT: Controls Horizontal Image Position within the display area on the LCD. UP/DOWN: Controls Vertical Image Position within the display area of the LCD. H. SIZE: Adjusts the horizontal size by increasing or decreasing this setting. -
Page 9: Touch-Screen Information
The Touch screen driver software provided on Product CD is a downloaded copy from the following listed companies. Aydin Displays Inc does not warrant any of the touch software. The driver software has been downloaded from the appropriate web sites and is only updated every January. Please refer to the appropriate web site for the latest updates. -
Page 10: Visual Performance
VECTOR 15 SPECIFICATIONS: Visual Performance: Display Type: 15.0” TFT Active-Matrix LCD Active Display Area: 304mm x 228mm (12.0in x 9.0in) Pixel Pitch: 0.30 mm Luminance: 250cd/m (typ.) Contrast Ratio: 400:1 (typ.) Resolutions Supported: 720 x 400 :VGA text 640 x 480 @ 60-75 Hz 800 X 600 @ 56 -75 Hz... -
Page 11: Troubleshooting
TROUBLESHOOTING: NO PICTURE: • If the Amber NO SYNC LED is lit, verify that the signal cable is properly connected to the display and computer. • The Green ON LED should be lit. IMAGE PERSISTENCE: • Image persistence is when a “ghost” of an image remains on the screen even after the monitor has been turned off. - Page 12 VFP15 RACK MOUNT Document No. 150-VFP5-003 Rev. A, May 2004...
- Page 13 VFP15 PANEL MOUNT Document No. 150-VFP5-003 Rev. A, May 2004...
