USERS GUIDE MODEL 4424S 24 INCH AMLCD COLOR MONITOR P/N 356-7040-501 Document No. 150-4424-002 Rev. (A), February 2012... - Page 2 NOTICE This manual is subject to change without notice and should not be construed to be a commitment in any form by Aydin Displays. All trademarks and registered trademarks are recognized as the property of their respective owners. Doc. No. 150-4424-002 Rev. (A), February 2012...
- Page 3 WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
- Page 4 PRODUCT SAFETY PRECAUTIONS Follow all warnings and instructions marked on the display. Do not attempt to service this display yourself. Removing the display cover or back may expose you to dangerous voltage or other risks. Refer all servicing to qualified service personnel. Adequate ventilation must be maintained to ensure reliable and continued operation and to protect the display from overheating.
- Page 5 Thank you for purchasing this Aydin Displays LCD Display. The carton contains the items listed below: • 4424S LCD Display • Product CD containing: – This User’s Guide – Warranty Guide Please check the carton and its contents for damage that may have occurred during the shipment.
-
Page 6: Table Of Contents
Table of Contents CONNECTIONS AND SETUP ................3 Power Connections....................3 I/O Connections....................3 1.2.1 VGA Video Signal Connections..................3 1.2.2 DVI Digital VIDEO Signal Connections ................4 1.2.3 Host Computer Interface (RS232) Connections.............. 5 DISPLAY ADJUSTMENT.................. 6 Control Panel Function Buttons .................6 2.1.1 LCD Adjustment Pushbuttons .................. - Page 7 4424S DISPLAY FEATURES Capable of displaying 16,772,166 colors: The display’s high-contrast LCD enhances color vibrancy and improves focus with no geometric distortion. Multiple Frequency Technology: Automatically adjusts the display to the video card’s scanning frequency, thus displaying the resolution required. Wide viewing angle: ±80°...
-
Page 8: Connections And Setup
CONNECTIONS AND SETUP To connect the LCD display to your system, follow these instructions: CAUTION: Turn power off to the computer, display, and power supply before making any connections. The power ON/OFF switch designations are as follows: Power Connections AC operating input voltage is single phase, 115 VAC, 60 Hz. Voltage: 88 - 264 VAC Auto-ranging, Single-phase (115 VAC typical) Frequency:... -
Page 9: Dvi Digital Video Signal Connections
Pin # Description Pin # Description Red Video Input DDC +5VDC (EDID power) Green Video Input Sync Return Blue Video Input No Connection No Connection DDC Data (EDID SDA) DDC Ground (EDID) H-sync/Composite sync Red Video Return V-sync Green Video Return DDC Clock (EDID SCL) Blue Video Return 1.2.2 DVI Digital VIDEO Signal Connections... -
Page 10: Host Computer Interface (Rs232) Connections
1.2.3 Host Computer Interface (RS232) Connections Connect an RS232 Serial Cable (not provided) to the DB9 female RS232 input connector on the back of the unit to the host computer RS232 Interface. Pin assignments for the DB9 female connector are shown below. Signal Signal Signal... -
Page 11: Display Adjustment
DISPLAY ADJUSTMENT If you have any problems connecting, setting up or operating the display, please refer to the Troubleshooting section of this guide. Plug the LCD power cord into an AC power source. Turn ON the power switch and the green ON LED should light. -
Page 12: Front Panel Indicators
2.1.2 Front Panel Indicators LED indicators located on control panel: NO SYNC (Amber) – Indicates that the monitor is not receiving or cannot synchronize to the external video input. POWER (Green) – indicates that the monitor is powered. 2.1.3 Power Management When Horizontal or Vertical Sync is not detected, the amber NO SYNC indicator will light and the No Sync symbol will appear (see below). -
Page 13: On-Screen Control Function Items
On-Screen Control Function Items 2.2.1 OSD (ON SCREEN DISPLAY) – PRE ADJUSTMENT NOTICE 2.2.1.1 OSD Timeout Period The OSD (On Screen Display) has a user-selectable Timeout Period. If the OSD is activated and no front panel control keys are depressed for a period of 5 to 60 seconds, the OSD will automatically deactivate. -
Page 14: Osd (On Screen Display) - Stored Values
2.2.2 OSD (ON SCREEN DISPLAY) – STORED VALUES Values chosen during OSD interaction are stored in memory under the following conditions: • The front panel “EXIT” is pressed • Timeout period expires Values chosen during OSD interaction are not stored in memory under the following conditions: •... -
Page 15: Osd Menu Navigation - Main Menu
2.2.3 OSD MENU NAVIGATION – MAIN MENU If the OSD is not visible, press the front panel “SELECT” key once to activate the OSD. Observe the following choices in the MAIN Menu Selection List: • Source - (Multiple Sub-Function Selection Buttons) •... -
Page 16: Osd Menu Navigation - Image Menu (Main Vga Mode)
2.2.4 OSD MENU NAVIGATION – IMAGE MENU (MAIN VGA MODE) If the OSD is not visible, press the front panel “SELECT” key, once, to activate the OSD. Press the front panel [ - ] or [ + ] keys to navigate to the IMAGE menu. NOTE: The IMAGE menu is available only when the VGA mode is selected as the MAIN picture mode. -
Page 17: Osd Menu Navigation - Color Menu
2.2.5 OSD MENU NAVIGATION – COLOR MENU If the OSD is not visible, press the front panel “SELECT” key once to activate the OSD. Press the front panel [ - ] or [ + ] keys to navigate to the COLOR menu. Observe the following choices in the COLOR Menu Selection List: •... -
Page 18: Osd Menu Navigation - Controls Menu
Press the front panel “EXIT” key one additional time to resume navigation in the Top- Level OSD menu. Pressing “EXIT” while in the Top-Level of the OSD menu will deactivate the OSD. 2.2.6 OSD MENU NAVIGATION – CONTROLS MENU If the OSD is not visible, press the front panel “SELECT” key once to activate the OSD. Press the front panel [ - ] or [ + ] keys to navigate to the CONTROLS menu Observe the following choices in the CONTROLS Menu Selection List: •... -
Page 19: Osd Menu Navigation - Osd/Reset Menu - Factory Reset
2.2.7 OSD MENU NAVIGATION – OSD/RESET MENU – FACTORY RESET If the OSD is not visible, press the front panel “SELECT” key once to activate the OSD. Press the front panel [ - ] or [ + ] keys to navigate to the OSD/RESET menu Observe the following choices in the OSD/RESET Menu Selection List: •... -
Page 20: Osd Menu Navigation - Osd/Reset Menu - Standard Functions
2.2.8 OSD MENU NAVIGATION – OSD/RESET MENU – STANDARD FUNCTIONS If the OSD is not visible, press the front panel “SELECT” key once to activate the OSD. Press the front panel [ - ] or [ + ] keys to navigate to the OSD/RESET menu Observe the following choices in the OSD/RESET Menu Selection List: •... -
Page 21: Osd Menu - Sample Images
2.2.9 OSD MENU – SAMPLE IMAGES MAIN (VGA) MAIN (DVI) IMAGE (VGA) COLOR CONTROLS OSD/RESET 150-4424-002(A).doc... -
Page 22: Remote Display Interface (Serial Control - Rs-232)
2.2.10 REMOTE DISPLAY INTERFACE (SERIAL CONTROL – RS-232) 2.2.10.1 RS-232 Serial Interface - Interrogation and Control RS-232 Serial Interface provides for the interrogation and control of the following display functions: • Main Source Select 2.2.10.2 Interface Protocol The Interface Protocol is standard asynchronous RS-232 serial I/O •... -
Page 23: Remote Display Interface - Function Messages
2.2.11 REMOTE DISPLAY INTERFACE – FUNCTION MESSAGES 2.2.11.1 Main Source (VGA / DVI) Select The Main Source control function provides the following options: • VGA (RGB) • DVI (Digital Video) Mode and Hex Value Data Table Main Source Input HEX Data HEX Data HEX Data (Read Range) -
Page 24: Maintenance
MAINTENANCE Field Maintenance should be limited to front panel adjustments, and external cleaning. Any action that requires opening the monitor chassis should be deferred to the depot or factory. PREVENTIVE MAINTENANCE The only periodic maintenance recommended is EXTERIOR SURFACE cleaning when necessary. -
Page 25: 4424S Specifications
4424S SPECIFICATIONS LCD Module Active matrix thin film transistor (TFT) liquid crystal display (LCD) Native Resolution (Pixel Count): 1920 (H) x 1200 V) Pixel pitch: 0.270 mm (H) x 0.270 mm (V) Aspect Ratio: 16:10 Viewing angle: ±80° (typical all directions with more than 10:1 contrast ratio) Contrast Ratio: 1000:1 typical (dark environment) Display colors: 16,777,216 Dimming Range: 0% to 100%... -
Page 26: Vesa Resolutions Supported
VESA Resolutions Supported NOTE Resolution is based on horizontal and vertical frequencies only. MODE VIDEO Vertical Horizontal Pixel Standard MODE Refresh Frequency Frequency Mode INPUT Rate 640 x 400 85 Hz 37.9 KHz 31.500 MHz 640 x 480 60 Hz 31.5 KHz 25.175 MHz 640 x 480... -
Page 27: Rs-232 Host Serial Interface
RS-232 HOST Serial interface Serial Interface Protocol Communication with the host is via an asynchronous RS232 standard serial I/O: one start bit, eight data bits, and one stop bit at 115.2 K baud. Only the transmit data (TX) and receive data (RX) signal lines are used (no handshaking). -
Page 28: Power Consumption
Power Consumption Input 115 VAC 60Hz single-phase at 0.945 Amps, 104 W (typ.) Dimensions See the dimension drawings at the back of this Users Guide. 4.10 Weight Rack (24-IN) or Console Mount: 24.2 lbs Nominal 4.11 Operating Environment ♦ Temperature: 0°C to 50°C; MIL-STD-810E Method 501/502, Procedure II ♦... -
Page 29: Non-Operating Environment
4.12 Non-Operating Environment ♦ Temperature: -20°C to +60°C; MIL-STD-810E, Method 501/502, Procedure I ♦ Transportation: MIL-STD-810E, Method 514, Procedure I, Basic Condition I-3.2.1, Common Carrier: Fig 514.4-1, 514.3-2, 514.4-3, 1 hour per axis, 3 axes ♦ Altitude: MIL-STD-810E, Method 500, 0 - 40,000 ft. above sea level 150-4424-002(A).doc... -
Page 30: Troubleshooting Tips
Consult the display card or system manual to change sized properly. graphics mode. • Check if the desired scaling factor is selected. If these troubleshooting tips do not solve your problem, contact Aydin Displays Customer Support at 610-404-5370 or fax us at 610-404-8186 150-4424-002(A).doc... -
Page 31: 4424S Display Dimensions
4424S DISPLAY DIMENSIONS For clarity, displays are shown without signal and power cables. 150-4424-002(A).doc... - Page 32 4424S DISPLAY DIMENSIONS CONT. 150-4424-002(A).doc...
