12. Connecting the power supply

Connect the Smart 16 IP to the power supply using the Power cord provided.

13. Rack mounting the Smart 16 IP

Use the plate and screws provided to mount the Smart 16 IP on a server rack as
illustrated below.
CAT5
SMART

14. Rack mounting the RICCs

You can attach the RICCs to a server rack or computer using the Velcro strips
provided. Or connect it using the bracket provided.
The figure below illustrates the bracket.
Insert screws through
bracket and into the
back of the RICC
INSTALLATION GUIDE
IP
SWITCH
Activity
Syste m OK
Insert screws to
connect to rack
Insert screws through
bracket and into the
rack
Insert screw through
bracket and into the
back of a computer
.
10
MINICOM
www.minicom.com
Insert screws through
bracket and into the
back of the RICC
Insert screws to
connect to Switch
side panel
