4.7.
FCN Interface – MGT Links
Eight lanes of user MGT (GTP) links are routed to the front panel connectors. Lanes 0 – 3
are routed through J5, lanes 4 - 7 are routed through J4.

4.7.1. Copper Mating Cables

Suitable cables are available from Fujitsu "microGiGaCN Cable I/O" range of 8-pair cables
in a variety of lengths and styles e.g. FCD-ZZ00001.
Molex provide an alternative source with their 'LaneLink' cables e.g. 74526 -1002

4.7.2. Optical Mating Cables

The optical interface uses external modules which plug in to the standard FCN style
connector. These modules (e.g. EMCORE QTR3432) convert the electrical signals to optical
format. Inter-module connection uses MJ3MM12RPR-10-0 (available from Fiberconnections
Inc.) or similar
Please note that these items are not normally supplied by Alpha Data.
ADM-XRC-5T2-ADV User Manual
Version 1.0
Page 11
FPGA
Signal
Pin
FCN_TX0_P
AA2
FCN_TX0_N
Y2
FCN_RX0_P
Y1
FCN_RX0_N
W1
FCN_TX1_P
T2
FCN_TX1_N
U2
FCN_RX1_P
U1
FCN_RX1_N
V1
FCN_TX2_P
R2
FCN_TX2_N
P2
FCN_RX2_P
P1
FCN_RX2_N
N1
FCN_TX3_P
K2
FCN_TX3_N
L2
FCN_RX3_P
L1
FCN_RX3_N
M1
FPGA
Signal
Pin
FCN_TX4_P
J2
FCN_TX4_N
H2
FCN_RX4_P
H1
FCN_RX4_N
G1
FCN_TX5_P
D2
FCN_TX5_N
E2
FCN_RX5_P
E1
FCN_RX5_N
F1
FCN_TX6_P
B1
FCN_TX6_N
B2
FCN_RX6_P
A2
FCN_RX6_N
A3
FCN_TX7_P
B6
FCN_TX7_N
B5
FCN_RX7_P
A5
FCN_RX7_N
A4

Table 6 FCN Interface - MGT Links

ADM-XRC-5T2-ADV User Manual
GTP
Number
FCN J5 Pin
112B
S16
"
S15
"
S1
"
S2
112A
S14
"
S13
"
S3
"
S4
116B
S12
"
S11
"
S5
"
S6
116A
S10
"
S9
"
S7
"
S8
GTP
Number
FCN J4 Pin
120B
S16
"
S15
"
S1
"
S2
120A
S14
"
S13
"
S3
"
S4
124B
S12
"
S11
"
S5
"
S6
124A
S10
"
S9
"
S7
"
S8
