SERVICE
MANUAL
Model C152 and C161
Soft Serve Freezer
Original Service Instructions
01/23/2017 (Original Publication)
085592-S
(Updated 7/29/2020)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C152 and is the answer not in the manual?

Questions and answers

Carman Nicholas Vernachio
July 8, 2025

locate the sight glass

0

Subscribe to Our Youtube Channel

Related Manuals for Taylor C152

Summary of Contents for Taylor C152

  • Page 1 SERVICE MANUAL Model C152 and C161 Soft Serve Freezer Original Service Instructions 01/23/2017 (Original Publication) 085592-S (Updated 7/29/2020)
  • Page 2 CAUTION: Information in this manual is intended to be used by Taylor service technicians only. Note: Continuing research results in steady improvements; therefore, information in this manual is subject to change without notice. Note: Only instructions originating from the factory or its authorized translation representative(s) are considered to be the original set of instructions.

  • Page 3: Table Of Contents

    Beater Door Assembly Model C161..............4-12 Accessories Model C152 ................. 4-13 Accessories Model C161 ................. 4-14 X86420-12—Control A. 115V 60HZ (Model C152) .......... 4-15 X85977-76 Control A. (Model C161)..............4-16 X86366 Control A.-Channel (Model C152) ............4-17 X69423 Control A.-Channel (Model C161) ............4-18 X59557-27 Box A.-Cap &...
  • Page 4 Notes: 085592-S...

  • Page 5: Section 1: Introduction/Safety

    Section 1: Introduction/Safety • Safety • Model C152 Specifications • Model C161 Specifications • General Installation Instructions • Environmental Notices • Running Specifications Introduction/Safety Model C152 & C161...

  • Page 6: Safety

    Machines that are permanently connected to safe operating and serviceable machines. The many fixed wiring and for which leakage currents may built-in safety features that are part of all Taylor machines exceed 10 mA, particularly when disconnected, are aimed at protecting operators and trained service not used for long periods, or during initial technicians alike.
  • Page 7 Authorized service personnel must ensure that the this machine. Failure to comply may result in personal proper personal protective equipment (PPE) is available injury or machine damage. and worn when required during installation and service. Introduction/Safety Model C152 & C161...

  • Page 8: Model C152 Specifications

    6-15P 208/230/60/1 Air 220-240/50/1 Air This machine may be manufactured in other electrical characteristics. Refer to the local Taylor distributor for availability. (For exact electrical information, always see the data label of the machine.) Air-Cooled Clearance: 4 in. (102 mm) on left and right, and 0 in. ...
  • Page 9 FIGURES IN BRACKETS INDICATE MILLIMETERS / DECIMAL AND FRACTIONAL DIMENSIONS EQUAL TO ( PLUS OR MINUS 1/16 INCH [1.5mm] ). DRAWING IS TO BE USED FOR REFERENCE ONLY - DO NOT USE FOR STORE CONSTRUCTION LAYOUT. 30070_A Figure 1-1 C152 with Cart C20800-W00 Introduction/Safety Model C152 & C161...

  • Page 10: Model C161 Specifications

    10.0 220-240/50/1 Water 10.0 This machine may be manufactured in other electrical characteristics. Refer to the local Taylor distributor for availability. (For exact electrical information, always see the data label of the machine.) Air-Cooled Clearance: 6 in. (152 mm) on left and right, and 0 in. ...
  • Page 11 FIGURES IN BRACKETS INDICATE MILLIMETERS / DECIMAL AND FRACTIONAL DIMENSIONS EQUAL TO ( PLUS OR MINUS 1/16 INCH [1.5mm] ). DRAWING IS TO BE USED FOR REFERENCE ONLY - DO NOT USE FOR STORE CONSTRUCTION LAYOUT. Figure 1-2 C161 with Cart C20700-W00 Introduction/Safety Model C152 & C161...

  • Page 12: General Installation Instructions

    Do not obstruct air intake and discharge openings.  Model C152 requires 4 in. (102 mm) of space on both Care should be taken to ensure that all basic safety sides, and no space at the rear of the machine. Model practices are followed during the installation and C161 requires 6 in.
  • Page 13 DO NOT operate this machine unless it is properly grounded and all service panels and access doors are restrained with screws. Failure to do so can result in severe personal injury from electrical shock! Introduction/Safety Model C152 & C161...
  • Page 14 It is recommended that the beater rotation adjustment be However any gas under pressure is potentially performed by a Taylor service technician. hazardous and must be handled with caution. NEVER fill any refrigerant cylinder completely with liquid.
  • Page 15 (1.6 m) from the floor. However any gas under pressure is potentially hazardous and must be handled with caution. NEVER fill any refrigerant cylinder completely with liquid. Filling the cylinder to approximately 80% will allow for normal expansion. 1-11 Introduction/Safety Model C152 & C161...
  • Page 16 INTRODUCTION/SAFETY Compressor Warranty Disclaimer It should be noted that Taylor does not warrant the refrigerant used in its machines. For example, if the The refrigeration compressor(s) on this machine are refrigerant is lost during the course of ordinary service to...
  • Page 17 GB/T 26572. X: Indicates that said hazardous substance contained in at least one of the homogeneous material for this part is above the limit requirement of GB/T 26572. 1-13 Introduction/Safety Model C152 & C161...

  • Page 18: Running Specifications

    Pressures °F °C psi (kPa) Soft Serve C152—Air-Cooled: 20 to 22 psi (138-152 kPa) for a 21.1 240 to 270 normal product of 16°F to 18°F (-8.8°C to -7.7°C). (1,655 to1,862) C161—Air-Cooled: 21 psi (145 kPa) for a normal product 26.7...

  • Page 19: Section 2: Controls

    Section 2: Controls • Generation II Control Logic Board • Service Tips for Generation II Boards • Control Overview • Refrigeration Schematic • Valve Functions Controls Model C152 & C161...

  • Page 20: Generation Ii Control Logic Board

    To monitor amperage, L1 power supplied to the beater motor must pass through the power board beater ™ terminals. The same Softech controls are used in both Controls Model C152 & C161...
  • Page 21 44ºF (6.6ºC) min. and approximately 30ºF (-1.1ºC) max. viscosity adjustment screw counterclockwise slowly until the machine cycles off. Setting Standby Temperatures 1. With the machine properly primed with fresh mix, turn the standby adjustment screw to the warmest position. Controls Model C152 & C161...
  • Page 22 88.296 31.760 -17.7 85.536 30.885 -17.2 82.863 30.035 -16.6 80.273 29.207 -16.1 77.765 28.403 -15.5 75.334 27.620 -15.0 72.980 26.859 -14.4 70.627 26.120 -13.8 68.350 25.400 -13.3 66.147 24.721 -12.7 64.014 24.059 -12.2 61.951 23.416 Controls Model C152 & C161...
  • Page 23 11.888 44.4 4.466 21.6 11.598 46.1 4.184 22.2 11.315 47.8 3.922 22.7 11.039 49.4 3.680 23.3 10.769 51.1 3.454 23.8 10.507 52.8 3.244 24.4 10.250 54.4 3.048 25.0 10.000 56.1 2.866 25.5 9.763 57.8 2.696 Controls Model C152 & C161...
  • Page 24 2.124 66.1 2.004 67.8 1.891 69.4 1.785 71.1 1.687 72.8 1.594 74.4 1.508 76.1 1.427 77.8 1.351 79.4 1.279 81.1 1.212 82.8 1.149 84.4 1.090 86.1 1.034 87.8 .982 89.4 .932 91.1 .886 92.8 .842 Controls Model C152 & C161...

  • Page 25: Service Tips For Generation Ii Boards

    Mix-Low light extinguishes. 2. The Fan relay closes and opens again. The  Mix-Out light extinguishes. 3. The Pump relay closes and opens again. The Mix light extinguishes. Controls Model C152 & C161...
  • Page 26 2. Rotate the adjustment screw back and forth from MIN to MAX. The bar graph should travel accordingly, indicating that the potentiometer is functional. If the bar graph lights do not react, the logic board is damaged. IMPORTANT! If the machine’s controls have Controls Model C152 & C161...

  • Page 27: Control Overview

    STANDBY MIN MAX MIN MAX SPARE SPARE 11.2 11.2 PUMP PUMP Power Board Power Board X69574-SER X69574-SER Ribbon Cable Plate A.-Dec 085802 (Includes Board) X85289 (Model C161) X85775 (Model C152) Ribbon Cable 085802 Figure 2-4 Controls Model C152 & C161...

  • Page 28: Refrigeration Schematic

    C161 (2) C161 (2) C152 (1) C152 (1) C161 (2) C161 (2) C152: 20-22 PSI (R404A) C152: 20-22 PSI (R404A) C161: 15-16 PSI (R404A C161: 15-16 PSI (R404A Access Valve (One Side Running for C161) C152: 20-22 PSI (R404A) C161: 15-16 PSI (R404A...

  • Page 29: Valve Functions

    (TXV). Automatic Automatic Expansion Valve of the Controls the refrigerant flow Expansion Valve Freezing Cylinder Circuit during the cooling of the freezing cylinder. (AXV) 2-11 Controls Model C152 & C161...
  • Page 30 CONTROLS Notes: 2-12 Controls Model C152 & C161...

  • Page 31: Section 3: Troubleshooting

    Section 3: Troubleshooting • General Troubleshooting Guide • Electrical Troubleshooting Troubleshooting Model C152 & C161...

  • Page 32: General Troubleshooting Guide

    Adjust the temperature control. is too cold. 6. Product is collecting a. The top O-ring on the draw valve is improperly a. Lubricate properly or replace the O-ring. on top of the freezer lubricated or worn. door. Troubleshooting Model C152 & C161...
  • Page 33 The mix inlet hole is frozen up. a. The hopper temperature needs adjustment. into the freezing b. Incorrect usage of the mix feed tube. b. Follow the correct feed tube procedures and cylinder. use of the air orifice. Troubleshooting Model C152 & C161...
  • Page 34 17. The buttons do not a. The wire harness is disconnected from the a. Remove DEC plate and verify that wire activate when DEC plate or the logic board. harness is connected to DEC plate and logic pressed. board. Troubleshooting Model C152 & C161...

  • Page 35: Electrical Troubleshooting

    L-1 power travels through the power switch, beater overload switch, compressor high-pressure cut-out switch, L-1 terminal of the power board, and Mix terminal of the power board, and energizes the hopper refrigeration compressor and condenser fan. Troubleshooting Model C152 & C161...
  • Page 36 TROUBLESHOOTING Notes: Troubleshooting Model C152 & C161...

  • Page 37: Section 4: Parts

    • Beater Door Assembly Model C152 • Beater Door Assembly Model C161 • Accessories Model C152 • Accessories Model C161 • X86420-12—Control A. 115V 60HZ (Model C152) • X85977-76 Control A. (Model C161) • X86366 Control A.-Channel (Model C152) • X69423 Control A.-Channel (Model C161) •...

  • Page 38: Warranty Explanation

    CAUTION: Warranty is valid only if required service work is provided by an authorized Taylor service technician. NOTE: Taylor reserves the right to deny warranty claims on equipment or parts if a unapproved refrigerant was installed in the machine, system modifications were performed beyond factory recommendations, or it is determined that the failure was caused by neglect or abuse.
  • Page 39 PARTS Notes: Parts Model C152 & C161...

  • Page 40: Model C152 Operator Parts

    PARTS Model C152 Operator Parts 14 15 Figure 4-1 Item Description Part No. Item Description Part No. Pan-Drip 085295 Shield-Splash 086379 Panel-Left 086378 Panel-Lower Front 086380 Cover A.-Hopper X49633-SP Panel-Front 086384 Tube-Feed 035819 Trim-Corner-Rear 086375 Panel-Rear 086376 Plate-Dec X85775 Panel-Right...

  • Page 41: Model C161 Operator Parts

    Panel -Side Left 085262 Shield-Splash 085304 Cover A.-Hopper 085351 Panel-Lower Front X85570 Tube-Feed 030797 Panel A.-Front 085678 Panel-Rear 085274 Shelf-Drip Tray 085698 Panel A.-Side-Right X69433 Orifice-Air 022465-100 Gasket-Base Pan 055815-SP O-ring-3/8 OD x .070W 016137 Parts Model C152 & C161...

  • Page 42: Model C152 Service Parts

    PARTS Model C152 Service Parts 39 51 42 43 Figure 4-3 Parts Model C152 & C161...
  • Page 43 PARTS Model C152 Service Parts Item Description Part No. Item Description Part No. Condenser-AC 12L x14H x 1.87T 046556 Shell A.-Insulated X86356-SER Bearing-Rear Shell 023648 Screw-10 x 3/8 Slotted Hex 015582 Tab-Bearing Lock 025027 Shroud-Fan 086381 Nut-Rear Bearing 023647 Fan-4 Blade 11” Push 30...
  • Page 44 Harness-Trans Relay 086256-12 Valve-Access-1/4 FL x 1/4 044404 Screw-5/16-18x1-1/2 Hex 001894 Washer-5/16 USS Flat CR3 000651 Board-Logic-Gen 2.11 X69571SER3 Valve-EPR 1/4S 022665 Bracket-DEC-Plate 087311 Screw-8 x 1/4 SLTD Hex 009894 Plate-Mounting-Board 085565 Plate-A DEC X85775 Parts Model C152 & C161...

  • Page 45: Model C161 Service Parts

    PARTS Model C161 Service Parts 44 43 48 41 Figure 4-4 Parts Model C152 & C161...
  • Page 46 Screw-10x3/8 Slotted Hex 015582 Switch A.-Reed Interlock X65658-5 Cover-Cap.&Relay Box 055136 Grommet-Comp.-MTG 037428 Screw-10-32x1/2 SERR HWH 036054 *Not Shown Nut-10-32 Flange Locknut 020983 Motor-Fan 50 Watt 029770-27 “Fan-3 Blade 12 “” Pull” 063397 Shroud-Condenser 064356 4-10 Parts Model C152 & C161...

  • Page 47: Beater Door Assembly Model C152

    PARTS Beater Door Assembly Model C152 Figure 4-5 Item Description Part No. Item Description Part No Valve-Draw 024763-SP1 Cap-Design 1.010"ID-6 PT. 014218 O-ring-7/8 OD x.103W 014402 Bearing-Guide 014496 Door A.-3SPT 1.5qt VALOX X86373-SER O-ring-2-3/4 OD x .139W 019998 Pin A.-Pivot-Short...

  • Page 48: Beater Door Assembly Model C161

    Valve-Draw-Center 031164-SP Door A.-3SPT 1.5qt Valox X56906SER3 Bearing Guide 014496 Pin A.-Pivot -Short* X38539 O-ring-2-3/4 OD x.139W 019998 O-ring-5/16 OD x.070W 016272 Bearing Front 023262 Handle-Draw 085615 Beater A.- X24689 Nut-Stud 056802-SP Seal-U-Cup 080534 4-12 Parts Model C152 & C161...

  • Page 49: Accessories Model C152

    PARTS Accessories Model C152 Apply the appropriate Taylor approved food safe lubricant. Figure 4-7 Item Description Part No. Item Description Part No. Pail-6·qt. 023348 Lubricant-Taylor·4·oz. 047518 Brush-Rear BRG 1” D x 2” LG 013071 Kit A.-Tune-Up X25802 Brush-Double-Ended 013072 Sanitizer Kay-5 25 PKTS...

  • Page 50: Accessories Model C161

    PARTS Accessories Model C161 Apply the appropriate Taylor approved food safe lubricant. Figure 4-8 Item Description Part No. Item Description Part No. Pail-6·qt. 023348 Lubricant-Taylor·4·oz. 047518 Brush-Rear BRG 1” D x 2” LG 013071 Kit·A.-Tune·Up X31167 Brush-Double·Ended 013072 Sanitizer Kay-5 25 PKTS...

  • Page 51: X86420-12-Control A. 115V 60Hz (Model C152)

    PARTS X86420-12—Control A. 115V 60HZ (Model C152) Figure 4-9 Item Description Part No. Item Description Part No. Box A.-Control *C152* X86416 Harness-Wire BTR MTR *C152* 086255 Screw-8x1/4 SLTD Hex Washer 009894 Screw-10-32x5/8 Taptite Hex HD 039382 Strap-Capacitor 5-5/8 in. 030258...

  • Page 52: X85977-76 Control A. (Model C161)

    X69574-SER Block-Terminal 3 Pole Green 080968 Fuse-.063A-250V-5x20mm 051272 Plate-End Terminal Block 080969 Screw-6-32x5/8 UNSLTD 041363 Harness-Wire-Cntrl Box 069129-27 Contactor 230VAC 1PH 055248-27 Harness-Wire-Main 069219-27 Overload-Thermal-2P 055249-27G Harness-Trans/Relay 069278-27 *Not Shown **Part of 069278-27 Harness 4-16 Parts Model C152 & C161...

  • Page 53: X86366 Control A.-Channel (Model C152)

    PARTS X86366 Control A.-Channel (Model C152) Figure 4-11 Item Description Part No. Item Description Part No. Switch A.-Draw  X55234 Bracket-Switch 035524 (Includes Items 1a-1f) Spring-Comp.720x.063X2.00 023664 Bearing-Switch 029244 Actuator-Switch-Plastic 035609 Nut-Push On-1/2DIA. Shaft 039735 E-ring-1/4 IN-ZD 034962 Screw-4-40x5/8 SLTD 027219 Arm A.-Switch...

  • Page 54: X69423 Control A.-Channel (Model C161)

    (Includes Items 1a-1g) Bracket-Switch 085567 Bearing-Switch 029244 Spring-Comp.720x.063x2.00 023664 Nut-Push On-1/2DIA. Shaft 039735 Actuator-Switch-Plastic 035609 Screw-4-40x5/8 Sltd 027219 E-ring-1/4 in-ZD 034962 Switch-Lever-Spdt 027214 Arm A.-Switch X30736 Insulator-Switch 1/64 029099 Bushing-Snap 15/16 ID x 1-3/32 023396 4-18 Parts Model C152 & C161...

  • Page 55: X59557-27 Box A.-Cap & Relay (Model C161)

    059757 Strap-Capacitor 7-11/32 037890 Capacitor-Start 161-193UF/25 031790 Capacitor-Run 30UF/370V 038487 Relay-Start-Compressor 047067 Strap-Capacitor 5-5/8 IN. 030258 Screw-10x3/8 Slotted Hex 015582 Capacitor-Run 10UF/370V 059998 Bushing-Snap 11/16 ID x 7/8OD 010548 Harness-Wire-Cap/Relay 063975-27 * Not Shown 4-19 Parts Model C152 & C161...
  • Page 56 PARTS Notes: 4-20 Parts Model C152 & C161...

  • Page 57: Section 5: Parts List

    Section 5: Parts List • C152 Standard Machine • C152 ROHS Compliant • C152 Marine Machine • C161 Standard Machine • C161 ROHS Compliant • C161 Water-Cooled Machine • C161 Marine Machine Parts List Model C152 & C161...
  • Page 58 C152 Standard Machine Model C15212H000, 115V 60HZ 1PH A/C Tecumseh (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments Actuator-Switch-Plastic 035609 Draw Switch Arm A.-Switch X30736 Draw Switch Bearing-Front 023262 Bearing-Guide 014496 Bearing-Rear Shell *150 52 68* 023648 See X23648-SER Kit A.-Bearing Rear Beater A.
  • Page 59 027714-12 + Kit-Mounting-Compressor 047704 Condenser-AC-7x6x1.25-2 Row 027155 +Dryer-Cap. Tube .026 ID x 11, 048894 Condenser-AC-12LX14HX1.87T 3RW 046556 Main Cord-Power 045666 Core-Shrader-Valve-Teflon 037047 Cover A.-Hopper Black X49633-SP Decal-Clean Inst.-Hopper 019029 Decal-Troubleshooting 038374 Diagram-Wiring *C152* 086047-12 Door A.-1 Spout -1.5 qt X86373-SER...
  • Page 60 Dryer-Cap. Tube .026 ID x 11, 048894 Dryer-Filter-HP62 3/8 X 1/4S 048901 Eyelet-Reset Button 013739 Fan 4 Blade 11 " Push 30 Deg CW 027818 Gasket-Base Pan *C152* 086306 +Screw-10X7/16 UNSL TD HWH 066234 Gasket-Base Pan Gear-Reducer 025770-SER +Screw 1/4 20x3 Hex Head Cap...
  • Page 61 Tool -O-ring-Removal 048260-WHT Label-Caution-Ground-Cord Unit 032165 Label-SW-Power-Off/On-SYM 052632 Label-Condenser Sharp 059287 Label-Warn-Cover 051433-CAN Label-Warn-Elec-SGL-Small 032717-CAN Leg-4"-3/8-16 Stud-Plastic 024755 Lubricant-Taylor 4 oz. 047518 Lug-Grounding-4-14GA Wire 017667 +Screw-1/4-20x5/8 Serrated 017522 +Nut-1/4-20 Whiz Flange Lock 017523 Man-Oper 085592-M Motor-1/2 Hp 059742-12 +Capacitor-Run 35uf/370v 059756...
  • Page 62 Panel-Rear *C152* 086376 Panel-Left 086378 Panel-Right 086377 Panel-Skirt-Air *C152* 086649 Only for Machines with legs Trim-Corner-Rear *C152* 086375 Plate A.-DEC *C152* X85775 Complete w/Board Probe A.-Thermistor-FEM-0.25 X31602-38 Use X82397-SER Kit A.-Probe-Thermistor IP68 Probe A.-Mix *Square* X30922 +Disc-Probe *SQ Hole* 030965...
  • Page 63 Shroud-Fan 086381 Main Spring-Comp.720x.063x2.00 023664 Draw Switch Starter-1 Phase 2.5 to 4 066794-12J +Overload-Thermal-1P-2.5/4.0A 067461-1J +Button-Reset 066795-33 Support A.-Drip Tray *C152* X86382 Switch A.-Draw X55234 Bearing-Switch 029244 Bracket-Switch-*168* 035524 Insulator-Switch 1/64 ARMIT 029099 Nut-Push On-1/2DIA. Shaft 039735 Screw-4-40x3/4 UNSLTD HWH...
  • Page 64 Model C15212H000, 115V 60HZ 1PH A/C Tecumseh (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments +Arm A.-Switch X30736 +Spring-COMP.720x.063x2.00 023664 +E-ring-1/4 IN-ZD 034962 Switch A.-Reed Interlock Door X65658-5 Switch-Pressure 440 Psi Solder 048230 Switch-Toggle-4PDT*On-None-On 037394 Switch A.-Power Terminal-Low Voltage Ground 034455 Tray-Drip 086312...
  • Page 65 Aux - May Use X47701SER2 Complete Kit +Relay-Start-Compressor TL3G 047702-27 +Capacitor-Start-60UF-220/275V 047703 +Dryer-Cap. Tube .026 ID x 8F 048725 Contactor 230VAC 1PH 50/60HZ 055248-27 Cord-Power 025340-27 Diagram-Wiring *C152* 086047-27 Harness-Trans Relay A. 086256-27 Kit A.-Motor-Fan X62253-27 Motor-1/2 Hp 059742-27 +Capacitor-Run 30MFD/370V 083338 +Capacitor-Start 130-156UF/330V 083339 +Screw-5/16-18x5/8 SERR.
  • Page 66 Model C15227H000, 208-230V 60HZ 1PH A/C Tecumseh (R404A) Description Part Number Qty. Warr. Class Comments Relay-Start-Compressor 048150 Main Relay-Start-Compressor TL3G 047702-27 Relay-Start-Compressor 048150 Main Starter-1 Phase 2.5 to 4 066794-27H +Overload-Thermal-1P-2.5/4.0A 067461-1H +Button-Reset 066794-1 Valve-Solenoid 7/64ORF x 1/4 043449-27...
  • Page 67 C152 ROHS Compliant Model C15240HW00, 220-240V 50 Hz 1PH A/C Tecumseh (R404A). ROHS Compliant Description Part Number Qty. Warr. Class Comments Block-Terminal 2P L1, N 039421 Compressor AKA9462ZXC-AK172JT 049302-40 +Capacitor Run 15UF/370V 027087 +Capacitor Start 72-88UF/330V 039567 +Relay Start Compressor...
  • Page 68 Optional Items Description Part Number Qty. Warr. Class Comments KIT A.-LEG/AIR SKIRT *C152* X86606 +PANEL-SKIRT-AIR *C152* 086649...
  • Page 69 C161 Standard Machine C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments Actuator Switch Plastic 035609 Draw Switch Arm A. Switch X30736 Draw Switch Bearing Front 023262 Bearing Guide 014496 Beater A. *150/152/162/16 X24689 Belt AX24 055201...
  • Page 70 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments Bushing Split 43/64ID x 7/8OD 027691 Control Box Bushing Snap 15/16 ID x 1 023396 Control Channel Button Reset Red Plastic 055249 +Eyelet Reset Button 013739 Cable Ribbon PWR Relay 60 in 032445...
  • Page 71 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments Coupling 3/8FS x 1/4FS 031791 Cover Hopper Black*161* 085351 Decal INST CLN HPR 019029 Decal Troubleshoot 038374 Diagram Wiring 085584-27S Door A. 3 Spout 1.5 qt Valox X56906SER3 Rod A.
  • Page 72 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments Gear A.*Reducer 4 to 1 Service 025770-SER +Screw 1/4 20x3 Hex Head Cap 025984 +Screw 1/4 20x3 1/4 Hex Head 025985 Harness Wire Cap/Relay 063975-27 Harness Wire Control Box 069129-27...
  • Page 73 Label SW Power Off/On SYM 052632 Label Warn Condenser SHAR 059287 Label Warn Cover 051433 Label Warn Elec TW Small 032718 Lubricant Taylor 4 oz. 047518 017667 Lug-grounding 4-14GA Wire 017522 +Screw-1/4-20x5/8 Serrated HWH 017523 +Nut-1/4-20 Whiz Flange Lock 055155-M...
  • Page 74 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments 085295 Pan-Drip 13-5/16 X85570 Panel A.-Lower Front 085572 +Bracket-Reset 049178 +E-Ring 3/16 .335 OD 1500-18P 013739 +Eyelet-Reset Button 013592 +Pin-Pivot X69433 Panel A.-Side Right 085678 Panel-Front 085262...
  • Page 75 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments 013496 Stud-Nose Cone-5/16-18x5/16-18 056802-SP +Nut-Stud 085304 Shield-Splash 064356 Shroud-Condenser 048818 Shroud Danfoss 023664 Spring-COMP.720x.063x2.00 Draw Switch X85704 Support A.-Drip Tray X85566 Switch A.-Draw 029244 Bearing-Switch 085567...
  • Page 76 C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine Description Part Number Qty. Warr. Class Comments 043729-L Terminal-FEM.SP.INS.22-18.25 034455 Terminal-Low Voltage Ground 034807 Tray-Parts-Barrel-1.5 qt-Twin Optional 085698 Tray-Drip 030797 Tube-Feed-.166 Hole-SS-TM 044404 Valve-Access 1/4FL x 1/4 Sold Line Suction DANF 053565 Valve-Access-1/4MFL x 3/8ODS Line Access DISCCHG/Low...
  • Page 77 C16140FW00, 220 240V 50Hz 1PH, A/C Bristol (R404A), ROHS Compliant Description Part Number Qty. Warr. Class Comments 066395-95 Cord Power Harmonized 085584-40S Diagram Wiring *161* 055097-40G Motor 1/2 HP Remote Caps 059998 +Capacitor Run 10UF/370V 059759 +Capacitor Start 88 108UF/ C161 Water-Cooled Machine C16127R000, 208 230V 60Hz 1PH W/C Bristol (R404A) Standard Machine Description...
  • Page 78 C161 Marine Machine C16127 208-230v 60hz 1ph A/c Bristol (R404a) Marine Machine Description Part Number Qty. Warr. Class Comments X69433-SPN Panel A.-Side Right *161* X85729SER1 Panel A.-LWR Frnt-Complet 085262-SPN Panel-Side *161*L* 085274-SPN Panel-Rear *161*AC 085584-40M Diagram-Wiring *C161 MARI 085678-SPN Panel-Front *C161* 069129-40 Harness-Wire-Control Box 080967...

  • Page 79: Section 6: Wiring Diagrams

    Section 6: Wiring Diagrams • Diagram 086047-12 (C152) • Diagram 086047-12M (C152) • Diagram 086047-27 (C152) • Diagram 086047-27M (C152) • Diagram 086047-40 (C152) • Diagram 085584-27S (C161) • Diagram 085584-40M (C161) • Diagram 085584-40S (C161) Wiring Diagrams Model C152 & C161...
  • Page 80 WIRING DIAGRAMS Taylor Company Model C152 086047-12 04/18 Figure 6-1 Diagram 086047-12 (C152) Wiring Diagrams Model C152 & C161...
  • Page 81 WIRING DIAGRAMS Taylor Company Model C152 086047- 12M 05/18 Figure 6-2 Diagram 086047-12M (C152) Wiring Diagrams Model C152 & C161...
  • Page 82 WIRING DIAGRAMS Taylor Company Model C152 086047-27 04/18 Figure 6-3 Diagram 086047-27 (C152) Wiring Diagrams Model C152 & C161...
  • Page 83 WIRING DIAGRAMS Taylor Company Model C152 086047-27M 05/18 Figure 6-4 Diagram 086047-27M (C152) Wiring Diagrams Model C152 & C161...
  • Page 84 WIRING DIAGRAMS Taylor Company Model C152 086047- 40 04 /18 Figure 6-5 Diagram 086047-40 (C152) Wiring Diagrams Model C152 & C161...
  • Page 85 WIRING DIAGRAMS Taylor Company Model C161 085584-27S 10/18 Figure 6-6 Diagram 085584-27S (C161) Wiring Diagrams Model C152 & C161...
  • Page 86 WIRING DIAGRAMS Taylor Company Model C161 085584-40M 10/18 Figure 6-7 Diagram 085584-40M (C161) Wiring Diagrams Model C152 & C161...
  • Page 87 WIRING DIAGRAMS Taylor Company Model C161 085584-40S 10/18 Figure 6-8 Diagram 085584-40S (C161) Wiring Diagrams Model C152 & C161...
  • Page 88 WIRING DIAGRAMS Notes: 6-10 Wiring Diagrams Model C152 & C161...
