Following the procedure described below for VESA mounting.
Secure the wall-mount kit to the monitor using the 4 screws provided
Slide the computer into wall-mount kit and secure it with the 4 screws provided
Attach four M4 screws on the wall and hang the system on the screws.
Ensure that the wall structure is capable of supporting four times the total weight of mounted
equipment. The total weight capacity of the wall-mount kit is 14kg.
QDSP-2030 User's Manual
Figure 13 VESA Mounting
WARNING
27
Chapter 2
