Assembly/Disassembly
Accessing Internal Components
Before opening your system, make sure to turn it off and disconnect the power
sources to prevent electric shock or system damage.
Follow the procedure described below to access the system's internal components
1.
Loosen the 3 flathead screws from rear side of the computer.
2.
Remove the chassis cover off the chassis base.
QDSP-2030 User's Manual
Chapter 2
WARNING
Figure 2 Remove Chassis Cover
18
