Audio (For Future Development); Alarms And Relays (For Future Development) - Dedicated Micros DV-IP Decoder Installation And Operation Manual

Monitors
8 & 4 output units
MON1 to MON4/MON8
HDMI x2

Audio (for future development)

Audio IN (Dual)
Audio OUT (Dual)
Data
SERIAL 1
SERIAL 2
SERIAL 3
SERIAL 4
USB
IR
NET1
NET2
KBD
EXP

Alarms and relays (for future development)

ALARMS IN
RELAYS
Power
POWER
Dedicated Micros ©2010
75Ω BNC composite monitor output, 1V pk-pk
High-Definition Multimedia Interface connectors (High Definition 8
output model only)
RCA (phono) socket, 8KHz/16KHz/22KHz sampling 75Ω input
impedance, 1V pk-pk for future development
RCA (phono) socket, line level <100Ω output impedance,
1V pk-pk amplification required for future development
RS-232 (3 wire & 9 wire)
RS-232 (3 wire & 9 wire)
RS-485 (2 wire) or RS232 (5 wire)
RS-485 (2 wire) or RS232 (5 wire)
2x USB2.0 connectors
Infra-Red Input connector for IR Remote Control Extender
RJ45 Ethernet network connector, 10/100 Mb/s Ethernet Network
RJ45 Ethernet network connector, 1 Gb/s Ethernet Network
RJ12 expansion port for future development
RJ12 expansion port for future development
25-way (female) D Type port for future development
9-way (female) D Type port for future development
IEC mains power socket & switch
9
