Installing the Unit
Before you start
Check the contents of the box
Remove all items from the packaging and check the items listed below are present:
•
DV-IP Decoder (either 4 or 8 input)
•
USB Mouse
•
IR Remote Control
•
IR Remote Control Extender
•
Power Leads
•
Rack mounting brackets
If any of these items are missing, please contact Dedicated Micros Technical Support team.
Note: Before installing the DV-IP Decoder, carefully read all Safety Instructions and the following
information on where the unit should be located.
Choosing a location for installation
•
The DV-IP Decoder is designed to be desk, shelf or rack mounted.
•
Ensure the DV-IP Decoder is properly ventilated to protect from overheating.
•
Ensure there is a 3cm gap on both sides of the unit.
•
Ensure the receiving end of the IR remote control extender faces the operator position
and is not more than 3 metres (10 feet) from the operator.
•
Ensure the unit is not located anywhere it could be subject to mechanical shocks.
•
The unit should be located in an area with low humidity and a minimum of dust. Avoid
places like damp basements or loft spaces.
•
If the unit is to be installed in a closed assembly, the maximum operating temperature
must not exceed 40°C (104°F).
•
Ensure there is reliable earthing of the mains outlet when fitted to supply connections
(other than direct connection to the branch circuit).
•
Any branch circuit supplying the unit must be rated at 15Amps.
•
It is recommended that an uninterrupted power source be connected to the unit in case
of power failure (to ensure continuous operation of the unit).
Please ensure the following are available and have been tested prior to the installation:
•
Mains point
•
Network point
•
Network cable
•
Active video signals i.e. at least one working camera feed
•
PC with CD ROM drive and connection to the same network as the DV-IP Decoder unit
(Recommended)
Dedicated Micros ©2010
7
