Secondary Web Port
Telem UDP Port Selection
Telemetry Port
Note: This option will only be displayed when 'User Defined' is selected in the Telem UDP Port
Selection option.
Samba Workgroup
Note: A unit reset is required to activate/update Samba Workgroup details.
User Logging
Comb Filter
Auto Update Web Variables
Enable External Modules
Automatic FTP Download
Note: When de-selected here, the 'Automatic FTP Download' menu will no longer be displayed in
the menu tree.
Webcam Support
Note: When de-selected here, the 'Web Cam' menu will no longer be displayed in
the menu tree.
SMB server support
28
(rate/quality/resolution) is identical to that being recorded.
If the default port setting for web serving has already been
allocated, it is possible to configure a second port number
i.e. the secondary web port can be set to 8000 if the default web
port (80) is blocked by the network or firewall.
Select 'Automatic' to enable the unit to select a suitable port for
telemetry purposes.
Select 'Default' to use the default port settings (1025).
Select 'User Defined' to use settings entered in the 'Telemetry
Port' option.
Enter the port settings for telemetry data here. The default setting
is 1025.
Enter the Samba (SMB) Workgroup details.
Enable this option to activate User Logging. Refer to 'Appendix C'
for further information regarding the User Logging function.
Enable this option to activate the Comb Filter function. Comb
Filter can help improve the fine details of a video signal image by
filtering the luminance and chrominance separation process.
Configures the unit to update all system variables required for an
automatic upgrade without requiring confirmation. Do not check
this box if you run a customised applet.
Select to enable any connected RS485 alarm modules.
Select this option to enable automatic FTP downloads to
download information from the unit and/or the webpages, refer to
'Network Settings->FTP Download' for more information.
Select this option to activate the Webcam function. This allows the
unit to emulate a webcam and send image from one video feed
in webcam format, refer to 'Network Settings-Web Cam' for more
information.
Select this option to activate the SMB (Server Message Block) file
sharing function.
When activated, the SMB protocol allows the unit to access PCs
operating the Windows operating system (and Linux machines
running Samba). This enables sharing of files and directories to/
from the unit. The name of the SMB Workgroup on the network
must be correctly entered in the SMB Workgroup option (see
below). It is important that the Server Name assigned to the
unit via 'Network Settings->Server Name' is unique within the
workgroup being used.
To access the unit via a PC running SMB (and has access to the
same Workgroup); open My Network Places->Entire Network-
>Microsoft Windows Network. The Workgroup containing the unit
and PC(s) should then be available. Files and folders can then be
copied/added as required.
