Page 1: Table Of Contents
4.2 Main Function 4.3 Home Position Adjust 5. How To Control The Unit 5.1 Master/Slave Built-In Preprogrammed Function 5.2 Easy Controller 5.3 iSolution Operation / DMX Controller 5.4 DMX 512 Configuration 5.5 DMX 512 Connection 6. Troubleshooting 7. Fixture Cleaning User Guide Широкий... -
Page 2: Safety Instruction
1. Safety Instruction Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or Please read carefully the instruction, which includes important moisture. information about the installation, usage and maintenance. Never touch bulb with bare fingers, as it is very hot after using. WARNING Hot lamp explosion hazard. -
Page 3: Technical Specification
8 Channels: Luminous intensity: 2. Technical Specification Power supply - AC 120V~60Hz or AC 230/240/250V~50/60Hz Channel 1 = Pan Channel 2 = Tilt Lamp - HMI 575W / HMQ 575/2 lamp base:SFc10-4 Channel 3 = Shutter Optical system Channel 4 = Gobo - High efficiency optical system Channel 5 = Color - High quality optical lens and dichroic colors... -
Page 4: Lamp
3. Lamp 4. How To Set The Unit In case of replacement of the lamp or maintenance, do not open the 4.1. Control Panel fixture within 15 minutes until the unit cools down after switching off. Because of its high internal pressure, there might be a risk that the Discharge lamp would explode during operation. -
Page 5: Main Function
4.2. Main Function Channel Mode To select any of the pre-set functions, press the MENU button up to when the required one is shown on the display. Select the function by ENTER button and the display will blink. Use Press the MENU button up to when the is shown on the display. - Page 6 the MENU button. Blackout Mode Display normal mode for the fixture putting on the floor. Press the MENU button up to when the is shown on the display. Pressing ENTER Display inversion mode for the fixture fixing under ceiling. button and the display will blink. Use DOWN and UP button to select the (yes Gobo1 focus Adjust blackout) or...
-
Page 7: Home Position Adjust
(Lamp off) mode. Once the mode has been selected, press the ENTER button to Pan offset setup or automatically return to the main functions without any change after 8 seconds. To go back to the functions without any change press the MENU button again. Press the MENU button for at least 5 seconds into offset mode, use DOWN and UP button up to when the is shown on the display. -
Page 8: How To Control The Unit
5. How To Control The Unit Gobo 1 offset You can operate the unit in three ways: Press the MENU button for at least 5 seconds into offset mode, use DOWN and UP button 1. By master/slave built-in preprogram function 2. -
Page 9: Isolution Operation / Dmx Controller
(LED slow blinking) (LED on) (LED fast blinking) 5.3.1 iSolution Operation ·Consistent DMX configuration enable iMove to be linked with iRock and iShow together and controlled at the same time. ·DMX address can be set remotely by iLead controller ( please refer to the user manual of iLead controller ). -
Page 10: Dmx 512 Connection
5.5. DMX 512 Connection The DMX 512 is widely used in intelligent lighting control, with a maximum of 512 channels. 1. If you use a controller with 5 pins DMX connector, you need to use a 5 to 3 pin adapter. 2. -
Page 11: Troubleshooting
6. Troubleshooting G. If The pan belt is broken Following are a few common problems that may occur during operation. Here are 1. Turn off the main power. some suggestions for easy troubleshooting: 2. Unscrew all the screws (A) and open the base-housing cover (B). A. - Page 12 Pay attention to the belt tension when install the belt. H. If The tilt belt is broken 1. Turn off the main power. Please refer to the photos below: 2. Unscrew all the screws (A) and open the right arm cover (B). 3.
-
Page 13: Fixture Cleaning
7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
