Summary of Contents for ACME LED-212RGB
-
Page 1: Table Of Contents
LED PANEL 2. Technical Specifications 3. Installation 4. How to set the unit 5. How to control the fixture 6. DMX512 Configuration 7. DMX512 Connections 8. Troubleshooting 9. Fixture Cleaning LED-212RGB User Manual Please read the instructions carefully before use... -
Page 2: Technical Specifications
1. Safety Introductions To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. Do not open the unit within five minutes after switching off. Please read the instructions carefully which includes important The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly information about the installation, operation and maintenance. -
Page 3: How To Set The Unit
○ 1 3DMX input: For DMX512 link, use 3/5-pin XLR plug cable to input DMX signal. 4. How To Set The Unit ○ 1 4Mains input C onnect to supply mains power. ： ： ： ： 4.1 Control Panel ○ 1 5Mains output ：... - Page 4 Channel mode Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to select the (channel 1) (channel 2) or (channel 3) or (channel 4) mode. Once the mode has been selected, press the ENTER button to setup or automatically return to the main functions without any change after 8 seconds.
- Page 5 again. Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to select the (sound control on) or (sound control off). Once the mode has been selected, press the Led Display ENTER button to setup or automatically return to the main functions without any change after 8 seconds.
-
Page 6: How To Control The Fixture
5. How to control the fixture Blackout To blackout all the fixture Function Strobe Select Color Select show Select Chase There are three ways to control the fixture 1. Synchronous strobe in white color Color 1-16 or Show 1-12 Chase 1-16 or fade A. -
Page 7: Troubleshooting
A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. - Page 8 particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics. Clean with soft cloth using normal glass cleaning fluid. Always dry the parts carefully. Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
- Page 9 Innovation, Quality, Performance...
