Camera User Manual
Introduction to the Visual Engineering line of Surveillance
Cameras
Visual engineering cameras can be recognised from their equipment label, the following part
numbers are described in this document:
MKIIID: 18 – 36 X Optical Zoom, IP67 PTZ Camera
MKIIIH: High Definition IP67 PTZ Camera
MKIXB: 36X Optical Zoom Forward Centre Camera
MKX: Micro Forward Center Pan and Tilt Camera
COS-X-XX: Micro Head Camera Flexible or Semi Rigid
PHC-XXX: Micro Pin Hole Cameras 15 – 70mm
SWZ: Miniature Pan and Tilt Camera
PPTZ-025010: Pin Hole Pan Tilt Zoom Camera
HHC: Camera Hand Controller for PTZ
DMMPTZC: Digital Multi Meter Controller for PTZ
MKIIID: 18 – 36 X Optical Zoom, IP67 PTZ Camera
Subject to change without notice
The MKIIID forms part of a line of highly integrated
surveillance products developed by Visual Engineering.
The device incorporates a high resolution block camera
based around one of either FCB-EX20D (10X low light),
FCB-EX990 26x optical zoom lens or FCB-EX1020E (36X).
An internal infra-red cut filter removal mechanism is used
to allow the camera to operate in both day and night
modes.
The PTZ utilises a VE standard connector providing power
and data to the unit.
The pan and tilt drive trains are actuated by gearless
stepper motors, reducing the operational noise to a
minimum. Pan and tilt speeds are zoom factor corrected,
giving fine control over the entire range of the lens.
Remote control of both the camera and pan and tilt drives
