Camera User Manual

Technical Section

Camera Specifications

MKIIID
Binder 12w
Interfaces
PTZ
Horizontal 360 degree
continuous
Vertical 270 degree
Presets Yes
Camera
Sensor 1/4'' Ex-
View HAD
CCD
Resolution > 520TVL
Sensitivity <0.7Lux
Signal to >50dB
Noise
Zoom 26 times
optical
Physical
Size 115*115*
175mm
Weight 2Kg
DC In 6 – 18V
Power 3.5W (6W
active)
Subject to change without notice
MKIIIH MK1XB MKX
Binder 12w Binder 8w Binder 8w
BNC
360 degree 60 degree 60 degree
continuous
270 degree 60 degree 60 degree
Yes Yes No
1/3'' Sony ¼'' Hyper 1/3''
FCB H11 HAD II CCD CMOS
> 1000TVL >550 TVL >550 TVL
<1Lux 1.4 Lux <0.008
Lux
>50dB >50dB >50dB
10 times 28 times N/A
optical optical
115*115* 200 * 184 60 * 51 *
175mm * 130mm 42mm
2Kg 1.5kg 50g
6 – 18V 6-18V 6-18V
3.5W (6W 6W active 1W active
active)
Visual Engineering Technologies Ltd.
SWZ PPTZ COS-XX
Binder 8w Binder Binder
8w 12w
360 60 N/A
degree degree
continuous
27 degree 60 N/A
degree
No Yes N/A
1/3'' 1/3'' 1/3''
CMOS CMOS CMOS
>550 TVL >550 TVL >520 TVL
<0.008 Lux <0.12 Lux <0.008
Lux
>50dB >50dB >50dB
10 times 4 times N/A
(switched)
55 * 55 * 123 * 23 * 12.5
70mm 117 * * 12.5
75mm mm
148g 215g 25g
6-18V 6-18V 5V
2W active 2.5W 350mW
active
PHC-XX
Binder
12w
N/A
N/A
N/A
1/3''
CMOS
>520 TVL
<0.03 to
0.24 Lux
>50dB
N/A
43 * 12 *
12mm +
lens
5V
350mW
E&OE
