Camera Interfaces

The cameras are provided with one of two interface connectors, an 8 pin or 12 pin Binder.
The interface has the following pin out.
VE 12 Pin camera connection.
Mating half : Binder 720 female, 12 pin P/N 99-9134-02-12
Pin Signal
+12V DC
1
2 P GND
CVBS
3
4 V GND
VE 8 Pin camera connection.
Mating half : Binder 620 female, 8 pin P/N 99-9226-00-08
Pin Signal
+12V DC
1
P GND
2
CVBS
3
Mating half : Binder 620 female, 8 pin P/N 99-9226-00-08 Pin Out
Subject to change without notice
Pin Signal
Reserved
5
6 + 5V DC
RS232 TXD
7
8 RS232 RXD
Pin Signal
VGND
4
RS232 TXD
5
RS232 RXD
6
Visual Engineering Technologies Ltd.
Pin Signal
Audio
9
10 A GND
Reserved
11
12 Reserved
Pin Signal
Reserved
7
Reserved
8
E&OE
