Summary of Contents for CYP CDP-13DPI
- Page 1 CDP-13DPI 1by 3 DisplayPort Extender Splitter Operation Manual CDP-13DPI...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Revision History
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
Table of Contents Introduction …………………………………………………..………. Applications …………………..…………………………....…. Package Contents ………………..………..……………....… System Requirements ……...………………..…..…………..……. Features …………………………………….……..……..……… Specifications ..……………………………………...………...…. Operation Controls and Functions ……………..……..……… 7.1 Front & Right Panel ..............7.2 Rear Panel …………..………………………………..…….… 7.3 Top Panel…………..………………………………..…….….. Timing tables for monitor …….......…………...……... Connection and Installation …….…..……………..…..…..…... -
Page 5: Introduction
1. Introduction For those who want to display large content the 1x3 DisplayPort Extender Splitter is for you. Able to extend an image onto 2 or 3 displays, this device is perfect for multi-tasking, but can also split an image so the same image is repeated on up to three connected displays. -
Page 6: Specifications
6. Specifications Output Resolution 1920 x 1200 / 1920 x 1024 Input port 1 x DisplayPort Output ports 3 x DisplayPort Power Supply 3.3V / 1.5A DC (US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ± 8kV (air-gap discharge) ±... -
Page 7: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Front & Right Panel DP OUT3 DP OUT2 DP OUT1 DP OUT 1~3: Connect these slots with the output displays Display port ① input port in order to send a signal. Note: It is suggested to use the same type/model of display in order to get the optimal image quality. -
Page 8: Top Panel
7.3 Top Panel LINK POWER CDP-13DPI 1x3 DisplayPort Extender Splitter ① LINK LED: The green LED will turn on when the input source device is connected. ② POWER LED: The green LED will switch on when the device is powered on. -
Page 9: Timing Tables For Monitor
8. Timing tables for monitor The 1 by 3 DisplayPort splitter is a smart device with a built in feature that can define which and how many monitors are connected and can transmit the proper signal for the display. Below is the expanded timing list which is sup- ported by the device. -
Page 10: Connection And Installation
9. Connection and Installation Dell PC/Notebook Dell Monitor Dell Monitor Dell Monitor Dell Monitor Dell Monitor Dell Monitor... -
Page 11: Acronyms
Acronyms Acronym Complete Term EDID Extended display identification data Graphics Processing Unit HDCP High-bandwidth Digital Content Protection... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20100329 MPM-CDP-13DPI...
