A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model.
CODE PART
A1 Hood (Pre-Assembled to Body)
HOOD A2 Hood Handle
A3 Warming Rack
B1 Barbecue Body
B2 Burner
B3 Control Panel
B4 Knob
B5 Hose (if supplied)
B6 Lava Rock in Basket
B7 Cooking Grill
B8 Ignition Button
BODY
B9 Control Panel Heat Shield
B10 Main Electrode
B11 Hinge Bracket
B12 Body Heat Shield
B13 Body Support
B14 Grease Cup Holder
B15 Grease Cup
C1 Trolley Handle
C2 Side Shelf (with bracket)
C3 Side Shelf (without bracket)
C4 Side Shelf Bracket A
C5 Side Shelf Bracket B
C6 Side Burner Knob
C7 Side Burner Grid
C8 Side Burner Shelf
C9 Side Burner
C10 Side Burner Electrode
C11 Side Burner Valve / Hose Assembly
TROLLEY C12 Left Front Leg
C13 Left Rear Leg
C14 Right Front Leg
C15 Right Rear Leg
C16 Hose Tidy
C17 Gas Bottle Holder
C18 Leg End Loop
C19 Wheel Spacer
C20 Wheel
C21 Axle
C22 Bottom Shelf
C23 Gas Bottle Strap
D1 M6x15 Bolt
D2 M5x10 Bolt
D3 M4x10 Bolt
D4 ST4.0x10 Screw
HARDWARE D5 ST4.0x15 Screw
D6 ST4.8x15 Screw
D7 M8 Locknut
D8 M5 Nut
D9 Shelf Spacer
Pre-Assembled Component
+ Quantity varies according to model purchased
V Appearance, size, and construction may differ according to model
OUTBACK®
QTY
EXCEL 100T
¥
1
¥
1
¥
1
¥
1
¥
1
¥
1
¥
2
+
¥
1
¥
1
¥
1
¥
1
¥
1
¥
2
¥
1
¥
2
¥
1
¥
1
¥
1
+
+
+
+
1
1
1
1
1
1
¥
1
¥
1
¥
1
¥
1
¥
1
¥
1
¥
1
¥
2
¥
2
¥
1
¥
1
¥
1
+
24
¥
4
1
¥
3
4
¥
2
¥
2
¥
2
+
2
OUTBACK® OUTBACK®
EXCEL 200T EXCEL 300T
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
1
1 1
1 1
1 1
¥
¥
¥
¥
¥
¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
28 28
¥ ¥
¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
¥ ¥
8 4
