RF Input Parameters
9.12
Data will be demodulated and then de-multiplexed by PID (Program ID). On demand, the
de-multiplexed data will be transmitted via the Ethernet switch to any of the devices
requesting such data.
Connection
Frequency Input Range
Input Level
Symbol rate
Modulation Scheme
Forward Error Correction modes
LNB Power
X-Digital Systems
XDS-PRO4
75 ohm F-type connector
950 to 2150 MHz
-65dBm to -25dBm
2 to 40 Msps
QPSK
Reed-Solomon and Viterbi (DVB-S)
20VDC 500mA MAX
46
R830001-1060 Rev B
