Digital Audio Output

9.8
The receiver has a single digital audio output port that provides AES/EBU versions of the
first two analog audio ports (Ports A and B). The Port A audio is located on the pair of
CH0 signals while the Port B audio is located on the pair of CH1 signals. The following
table contains the pin-out of the digital audio port.
PIN
1
2
3
4
5
6
7
8
9
Table 16. Digital Audio Output Pin-out
Connection
Format
X-Digital Systems
XDS-PRO4
FUNCTION
CH0_TX+
Ground
Not Connected
Ground
CH1_TX+
CH0_TX-
Not Connected
Not Connected
CH1_TX-
DB-9M
Balanced AES/EBU
Table 17. Digital Audio Output
