Rf Input Parameters - X-Digital System XDS PRO1 User Manual

Connection Rate
Number of Ports
Max Output IP Rate
VLAN

RF Input Parameters

8.10
Data will be demodulated and then de-multiplexed by PID (Program ID). On demand, the
de-multiplexed data will be transmitted via the Ethernet switch to any of the devices
requesting such data.
Connection
Frequency Input Range
Input Level
Symbol rate
Modulation Scheme
Forward Error Correction modes
LNB Power
XDS PRO1 Receiver User's Guide
X-Digital Systems
Rev A - August 29, 2009
10/100Base-TX (Auto)
2 external, 1 internal
Up to 20 Mbps (combined for all ports)
Each port is managed for VLAN use
75 ohm F-type connector
950 to 1450 MHz
-65dBm to -25dBm
2 to 40 Msps
QPSK
Reed-Solomon and Viterbi (DVB-S)
20VDC 500mA MAX
51
