M&C Interface Connector Pin-Outs
9.4
The Monitor and Control (M&C) port allows basic configuration of the XDS receiver via
an asynchronous RS232C electrical interface. It uses the following protocol settings:
115.2K baud, 8 data bits, No Parity, 1 stop bits, and no hardware flow control. In addition
to the asynchronous interface, the M&C connector provides a status relay output and four
optical inputs. The four optical inputs are activated grounding the input signal. The
following table provides the pin-out for the M&C port.
PIN
1
2
3
4
5
6
7
8
9
Table 7. M&C Port Pin-Out
Connection
Asynchronous Port
Relay Format
Optical Inputs
X-Digital Systems
XDS-PRO4
FUNCTION
Ground
TX
RX
ALARM
Ground
OPTO1
OPTO2
OPTO3
OPTO4
DB-9F
115.2K baud, 8 data bits, no parity, no hardware
flow control
1 Form A
4 Input Signals, Connect to ground to activate
Table 8. M&C Port
