The Programming Menu; The Programs Tab - X-Digital System PRO4 User Manual

The Programming Menu

6.2
From the Programming Menu, the user is able to view all of the programs and recordings
the receiver is equipped to receive and re-broadcast.

6.2.1 The Programs Tab

Each receiver is identified by the Network Management System as authorized to receive
and broadcast particular radio programs and as being part of certain airing networks.
From this tab, you can see which programs the receiver is set-up to receive and use. In
the Programs grid, you are given the Program Name, Code, Mono/Stereo Setting,
Program ID (PID), Authorization status, and Status for each Program on the receiver. In
the Airing Networks grid you see each Network the receiver may belong to and whether
it is currently authorized for this particular network.
Below is an image of the programs tab.
27
X-Digital Systems
R830001-1060 Rev B
XDS-PRO4
