Relay Outputs

9.5
There are two DB-37 connectors on the rear panel which together contain a total of 32
mappable relay (or contact) closures. The following tables provide the pin-outs for the
two relay connectors.
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
X-Digital Systems
XDS-PRO4
FUNCTION
RLY1A
RLY2A
RLY3A
RLY4A
Ground
RLY5A
RLY6A
RLY7A
RLY8A
Ground
RLY9A
RLY10A
RLY11A
RLY12A
NQ TxData
RLY13A
RLY14A
RLY15A
RLY16A
Table 9. Relay Port A Pin-Out
41
PIN FUNCTION
20 RLY1B
21 RLY2B
22 RLY3B
23 RLY4B
24 Ground
25 RLY5B
26 RLY6B
27 RLY7B
28 RLY8B
29 RLY9B
30 RLY10B
31 RLY11B
32 RLY12B
33 Ground
34 RLY13B
35 RLY14B
36 RLY15B
37 RLY16B
