The LCD Display and User Interface

4.2
The PRO4 Receiver comes equipped with a 128x64 pixel LCD on its front panel which
allows the user to view, modify, and save receiver settings. The navigation of the PRO4
receiver's menu hierarchy is simple:
- To cycle through the possible sub-menus, press the
- To navigate into the currently selected sub-menu, press the
- To navigate back up into a higher level of the menu hierarchy, press the
button.
- Once you have navigated to a menu which allows you to edit settings, use the
and buttons to highlight options, and the set button, to pick an option.
-

The Main Menu Options

When the receiver's front panel is not being used, the idle screen featuring the X-Digital
1
Systems logo will be displayed. There are two important statistics displayed on this
front logo screen: EB, energy per bit relative to noise floor, which is a quantitative
measure of signal quality; and AG, automatic gain, which is an indicator of the signal
level. Both of these quantities serve to describe the quality of the satellite signal and
should be used as a guide when positioning the satellite dish. Better signals have better
separation between the data and noise floor, and thus a higher EB. EB range is 0 - 18.
The receiver will fade in and out below 5 dB Eb/No, and loose lock completely at around
3.5 dB. A powerful signal will have a high AG (indicating little amplification is
required) while a weak signal will have a low AG (indicating unit is amplifying signal).
Once the button is pressed, the receiver will navigate into its main menu options.
These options are: STATUS, SETUP, and AUDIO PORTS. Continually pressing
) will cycle through these three main menus. Pressing
whichever one of these three options happen to be currently selected.
1
The X-Digital logo may be replaced by your broadcaster's logo.
X-Digital Systems
XDS-PRO4
or
or SET will navigate into
13
buttons.
button.
(or
R830001-1060 Rev B
