If your station is authorized to play any programs, you will now see a drop-down list
of programs which you may add to this station schedule. Select the program and live-
feed time that you wish to insert into this time slot and click "Next".
•
If you wish to play the program in its entirety, choose this option and click "Next". If
you wish to play only part of the program select this option, and then define which
portion of the program you wish to insert by following the instruction. Click "Next".
•
This page allows you to tell the receiver what to do with the feed when it receives it.
Playing the program live will not require use of the receiver's internal hard drive.
The other two options will store the program for later use. Click "Next" once you
have made your choice.
•
On the next page, select the days of the week that you wish to play this program.
Only days which this program is broadcast will be available for selection. If this
program is to be recurring, do not select an end date. Click "Next".
•
Confirm that all of your settings for this program are correct and click "Finish".
To delete or modify an already existing program on the schedule, click that program's
name. There is a delete link in the bottom right. You may also click previous to change
any of the program's settings.

Changing the Relay Mappings

7.3
There are 32 different relays on the PRO4 receiver, and each of these relays can
correspond to a different net-cue for a radio broadcast. You can use the NMS to specify
the relay mapping for the receiver. To do this
•
Click Relay Mappings at the top of the page beneath the X-Digital Systems logo.
•
Select the correct receiver from the receiver S/N drop-down list.
•
Click the "Edit" button in the bottom right.
•
Edit the text for the corresponding relay you wish to change.
•
When done changing relays, press "Save".
•
To cancel the changes you have made and to go back to the previous relay mapping,
click "Cancel".
Note!

Changing the Receiver's Time Zone

7.4
Using the Affiliate website it is also possible to change the receiver's time zone settings.
To do this, navigate to the Home page and select the appropriate time zone from the drop
X-Digital Systems
XDS-PRO4
Net-cues entered into the NMS's relay-mappings text box bust be
upper-case alphanumeric, i.e. only upper-case letters, or
numbers.
