PAD/ASYNC Output Port

9.9
The PAD port (Program Associated Data) relays information which is carried along with
the audio data received. I.e. song and artist information, or relay queues to trigger events.
Below is a pin-out table for the PAD port.
PIN
1
2
3
4
5
6
7
8
9
Table 18. PAD/ASYNC Output Port Pin-out
Connection
Asynchronous Port

Ethernet Port

9.10
Connection
Connection Rate
Number of Ports
Max Output IP Rate
VLAN

Modem (POTS) Port

9.11
Connection
Connection Rate
Format
X-Digital Systems
XDS-PRO4
FUNCTION
P0_TX
P1_TX
P2_TX
P3_TX
Not Connected
Ground
Ground
Ground
Ground
DB-9F
variable up to 115.2K baud, 8 data bits, no parity, no
hardware flow control
Table 19. PAD/ASYNC Port
RJ-45
10/100Base-TX (Auto)
3 external, 1 internal
Up to 20 Mbps (combined for all ports)
Each port is managed for VLAN use
RJ-11
14.4L, 28.8L, 56k
8Bits, No parity, One Stop
