Analog Audio Input

9.7
The receiver has one analog audio input port. The following table has the pin-out of the
analog input port.
PIN
1
2
3
4
5
6
7
8
9
Table 14. Analog Audio Input Pin-out
Connection
Format
Range
X-Digital Systems
XDS-PRO4
DB-9M
Balanced Pair L, R
-10 to +4dBu nominal (+22 max)
0.1% THD 85dB dynamic range
Table 13. Analog Audio Output
FUNCTION
L IN+
Ground
Not Connected
Ground
R IN+
L IN-
Ground
Not Connected
R IN-
DB-9M
Balanced Pair L, R
+4dBu nominal (+22max)
Table 15. Analog Audio Input
