QUICK START - FEATURES
MOUNTING/RIGGING
POINTS
SIDE RIGGING
POINTS
TOP & BOTTOM
RIGGING POINTS
REAR PANEL
RIGGING POINTS
REAR PANEL PULL-
BACK POINT
REAR PANEL
BRACKET MOUNT
INPUT PANEL
GRILLE RETENTION
SCREWS
NAMEPLATE
BARRIER STRIP
CONNECTOR
NL4-COMPATIBLE
LOCKING
CONNECTORS
PASSIVE / BI-AMP
SWITCH
BARRIER STRIP
CONNECTOR
NL4-COMPATIBLE
LOCKING
CONNECTORS
1) 150 lbs (68 kg) Working Load Limit / 15:1 safety factor
2) 60 lbs (27 kg) Working Load Limit / 15:1 safety factor

TABLE 1: iBOX FEATURES

(refer to FIGURE 1)
8 total, 2 top and 2 bottom on each side.
1
12 total
.
1
2 total
.
2
1 total
.
4-bolt pattern for OmniMount™ brackets or similar (iHP3500
Series has OmniMount bolt pattern on bottom).
For signal connections to the loudspeaker. Also contains Bi-
amp / Single-amp switch.
14 - #6 (16 on 3500 Series)
Community Logo.
Wired in parallel with both NL4-compatible locking
connectors.
4 pole NL4MP jacks, wired in parallel. Accepts NL4FC
connectors. Used for both PASSIVE and BI-AMPLIFIED
modes. Use terminals 1 ± for PASSIVE mode or for BI-
AMPLIFIED LF input. Use terminals 2 ± for BI-AMPLIFIED
HF input (not used in PASSIVE mode).
Used to select loudspeaker's operating mode. Down
position is for PASSIVE mode (single amplifier) and up
position is for BI-AMPLIFIED mode (separate LF and HF
amplifiers). Set-screw avoids tampering.
Wired in parallel with both NL4-compatible locking
connectors.
4 terminal NL4MP jacks. Accepts NL4FC in-line connectors.
Use terminals 1 ±. Terminals 2 ± are paralleled with 1 ±.
Also see Installation on Pages 24 - 26.
