Table 12: iHP-3500 Series Specifications*
Model iHP-3564
Three-Way, Full-Range
Type
Frequency 80Hz - 16kHz
Response ±4dB
Maximum Input
600W
Passive
Maximum Input LF 600W
Biamp MF/HF 100W
Recommended 1250W to
Amplifier 1800W @ 8Ω
Sensitivity 1W/1m 98dB SPL
Maximum Output
126 dB SPL
@1m
Nominal
8Ω
Impedance
Minimum
6.3Ω
Impedance
Nominal -6dB 60° H
Beamwidth 40° V
Crossover 500 Hz
Frequency 2 kHz
Recommended
50Hz 24dB/Oct 50Hz 24dB/Oct 30Hz 24dB/Oct 35Hz 24dB/Oct
HP Filter
LF 1 x 15"
Drivers MF 1 x 8"
HF 1 x 1.4"
Input 2 x NL4 +
Connectors Barrier Strip
13-Ply Baltic
Enclosure
Birch
Trapazoid 15°
Enclosure Angles
Sides
23 x M10
Mounting / Rigging and 4 x M8
(Omnimount)
Perforated
Grille Steel Foam
Backed
Community offers a wide variety of rigging / suspension
Optional
Accessories
Dimensions 36.42 / 925
H, W, D 21.00 / 533
in / mm 21.99 / 559
123 lb
Weight
55.8 kg
136 lb
Shipping Weight
61.7 kg
Community iBOX Installation/Operation Manual — Page 42
SPECIFICATIONS
iHP-3594 i-118S
80Hz - 16kHz 42Hz - 100Hz
±4dB ±3dB
600W 600W
LF 600W
N/A
MF/HF 100W
1250W to 1250W to
1800W @ 8Ω 1800W @ 8Ω
99 dB SPL 97 dB SPL
127 dB SPL 125 dB SPL
8Ω 8Ω
4.6Ω 7.1Ω
90° H 360° H
40° V 180° V
500 Hz
N/A
2 kHz
LF 1 x 15"
MF 1 x 8" 1 x 18"
HF 1 x 1.4"
2 x NL4 + 2 x NL4 +
Barrier Strip Barrier Strip
13-Ply Baltic 13-Ply Baltic
Birch Birch
Trapazoid 15° Trapazoid 15°
Sides Sides
23 x M10 23 x M10
and 4 x M8 and 4 x M8
(Omnimount) (Omnimount)
Perforated Perforated
Steel Foam Steel Foam
Backed Backed
accessories. See Pages 19 - 23 for details.
36.42 / 925 36.42 / 925
21.00 / 533 21.00 / 533
21.99 / 559 21.99 / 559
123 lb 99 lb
55.8 kg 44.9 kg
136 lb 118 lb
61.7 kg 53.5 kg
i-215LVS
Subwoofer
48Hz - 100Hz
±3dB
1200W
N/A
2500W to
3500W @ 4Ω
99 dB SPL
130 dB SPL
4Ω
4.2Ω
360° H
180° V
N/A
2 x 15"
2 x NL4 +
Barrier Strip
13-Ply Baltic
Birch
Trapazoid 15°
Sides
23 x M10
and 4 x M8
(Omnimount)
Perforated
Steel Foam
Backed
36.42 / 925
21.00 / 533
21.99 / 559
128 lb
58.1 kg
139 lb
63.1 kg
