INSTALLATION
Operating in Passive or Biamp Mode
All iBOX models except the i2W8 and iLF218 may be operated in either the passive mode or the bi-
amped mode, selected by a switch located on the input panel. This selector switch comes equipped with a set
screw to eliminate the possibility of an inadvertent change of switch position. The set screw must be removed
in order to alter the position of the switch. Table X shows Community's recommended DSP settings for iBOX
loudspeakers used in bi-amp mode. Note that three-way models use the internal mid-high passive crossover in
bi-amp mode.
HPF Slope
Model Freq dB
1244 60 24
1264 60 24
1266 60 24
1294 60 24
1296 60 24
1299 60 24
1544 60 24
1564 60 24
1566 60 24
1594 60 24
1596 60 24
1599 60 24
3564 50 24
3594 50 24
*LR = Linkwitz-Riley, BU = Butterworth
Recommended High-Pass Filters
When operating in either the passive or the bi-amplified mode, we strongly recommend the use of an
external, active high-pass filter to protect the cone drivers from excessive low frequency excursion. High-pass
filters will help protect the loudspeaker against damage from over excursion and will reduce low frequency wind
noise, turntable rumble, stage vibration, and other noises that result in a poorly defined and 'muddy' bass
response. Additionally, a high-pass filter will avoid using amplifier power that's wasted from attempting to
reproduce frequencies below the loudspeaker's intended operating range. Table 7 on Page 28 shows the
recommended filter settings for each iBOX model.
Table 6: DSP Settings for iBOX Biamp Operation
Low Frequency
LPF Slope
Filter* Freq dB
LR 1360 24
LR 1360 24
LR 1360 24
LR 1360 24
LR 1360 24
LR 1320 24
LR 1320 24
LR 1360 24
LR 1360 24
LR 1280 24
LR 1360 24
LR 1320 24
Low Frequency
LR 510 24
LR 450 24
Community iBOX Installation/Operation Manual — Page 27
