UG-213

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Qty Name
1 U1
1 U3
1 U2
2 SKD1, SKD2
1 C1
1 C2
2 C3, C8
2 C4, C5
2 C6, C9
1 C7
1 C10
2 J1, J2
2 J8, J9
4 LK11, LK12, LK13, LK14
1
1 LK1 to LK14
2 LK1, LK5
1 LK8
4 LK2, LK3, LK4, LK6
3 R1, R5, R10
3 R3, R4, RT
1 R6
3 X2, X3, X557
3 R7, R8, R9
2 J3, J13
7 A, B, DE_OUT, SKD1_PATCHWORK,
SKD2_PATCHWORK, T1, T2
8 D1, D1_PATCHWORK, D2,
D2_PATCHWORK, RE, RTS, RXD, TXD
2 GND2, X555
2 VDD2, X556
1 Only one header is required per board.

RELATED LINKS

Resource Description
ADM2485 Product Page, ADM2485 2.5 kV Signal Isolated, High Speed (16 Mbps), Half Duplex RS-485 Transceiver with Transformer Driver
ADP667 Product Page, ADP667 +5 V Fixed, Adjustable Low Dropout Linear Voltage Regulator
Description
ADM2485BRWZ, 16-lead SOIC_W
3.3 V to 6 V transformer/5 V to 6 V transformer
8-lead SOIC
ZPD10, DO35
Capacitor, Taj-B, 22 μF
Capacitor, 10 μF, 805
Capacitor, 0.1 μF, 805
Capacitor, 100 nF, 603
Capacitor, 603
Capacitor, 0.1 μF, 805
Capacitor, 22 μF
Connector, power
Terminal block, 4-way, CON\POWER4
Jumper, SIP-2P
Header, 2-row, 36 + 36-way
JUMPER-2, JUMPER_2_SWAP_AB
JUMPER-2
JUMPER-3
Resistor, 805, 51.1 Ω
Resistor, R1/8W
Resistor, 805, 100 Ω
Resistor, 805
Resistor, RES_1/2W_NARROW, 0 Ω
SMB
Test point
Test point
Test point
Test point
Rev. 0 | Page 8 of 12
Evaluation Board User Guide
Supplier/Part No.
Analog Devices ADM2485BRWZ
Coilcraft DA2304-AL (3.3 V) and
Coilcraft DA2303-AL (5 V)
Analog Devices ADP667
Fairchild Semiconductor 1N5817
AVX TAJB226K016R
Yageo (Phycomp)
CC0805KKX7R6BB105
AVX 08055C104KAT2A
AVX 0603YC104JAT2A
Do not insert
Do not insert
KEMET B45196E3226K409
LUMBERG KRM 02
CAMDEN CTB5000/4
Harwin M7566-05
Harwin M20-9983646
Harwin M7566-05
Harwin M7566-05
Harwin M7566-05
Multicomp MCTC0525B511JT5E
Not inserted
Vishay Draloric CRCW0805100RJNEAIF
Not inserted
Wire link
Vero 20-2137
Vero 20-313138
Vero 20-313140
Vero 20-2137
Vero 20-313137
