About Manual Inputting:
Rotate [DIAL] to input the 8 digit group ID, then push
[DIAL•ENTER].
• Push [16•9] to move the cursor forward, or [CH/WX•DUAL•U/
I/C] to move it backward.
• Push [CLR] to cancel and return to the DSC Set up menu.
• The first digit is specified as '0' for a Group ID.
• The first two digits are '0' for any Coast station ID.
--DSC Menu--
Input Address
Input 8 digits
0________
<CLR ˘ Exit / ENT ˘ OK>
e Rotate [DIAL] to select a desired intership channel, then
push [DIAL•ENTER].
• Intership channels are already preset into the transceiver in rec-
ommended order.
• After pushing [DIAL•ENTER], "Group Call Ready" is dis-
played.
--DSC Menu--
Select Intership CH
˘08
69
77
06
<CLR ˘ Exit / ENT ˘ OK>
r Push [DIAL•ENTER] to transmit the Group Call.
• Emergency channel (Channel 70) is automatically selected.
• If Channel 70 is busy, the transceiver stands by until the channel
becomes clear.
t After the Group Call has been transmitted, the following
message is displayed.
--DSC Menu--
Group Call
TX Complete
<CLR ˘ Exit>
y Push [CLR] to exit, and the transceiver automatically se-
lects the intership channel specified in step e.
• Even if [CLR] hasn't been pushed, the transceiver automatically
selects the specified intership channel in step e after 2 second
of inactivity.
6
DSC OPERATION
--DSC Menu--
Group Call Ready
<CLR ˘ Exit / ENT ˘ OK>
