MOTION DETECTION
CHANNEL-1 SENSITIV 0 (OFF)
AREA SETUP
CHANNEL-2 SENSITIV 1
AREA SETUP
CHANNEL-3 SENSITIV 5
AREA SETUP
CHANNEL-4 SENSITIV 2
AREA SETUP
PRESS (<,>) THEN (SELECT)
PRESS (MENU) TO EXIT
AREA SETUP: Used to define up to two zones per Channel where motion is to be
detected.
Selecting a "Channel Area Set Up" brings that Channel up full screen on the monitor.
A rectangle is displayed, which will define the top left hand corner as the first motion
detection zone. Use ▼ and ▲ buttons to move the rectangle up and down and
buttons to move the rectangle left and right. Use
set up the motion detection territory. Then use
Press button for the second motion detection zone and repeat the procedure above to
define its motion detection
MOTION SETUP MENU
MOTION SET UP
SENSITIVITY: Sets the sensitivity level for
Motion Detection. 0 (OFF) to 5 (maximum sensitivity).
▼ and ▲ buttons to select the sensitivity for
each Channel
button to select the level.
button to set the position and start to
▼, ▲ , , and to define the territory.
and
